Here 2 Gnss Gps Module + Pixhawk 4 Flight Controller Combo

US $199.00

San Clemente, California, United States
Aug 2nd

Open on mobile:
QR code

Includes anti-vibration mount plate. Pixhawk 4 Flight Controller: Main FMU Processor: STM32F765 32 Bit Arm® Cortex®-M7, 216MHz, 2MB memory, 512KB RAM IO Processor: STM32F100 32 Bit Arm® Cortex®-M3, 24MHz, 8KB SRAM On-board sensors: Accel/Gyro: ICM-20689 Accel/Gyro: BMI055 Magnetometer: IST8310 Barometer: MS5611 GPS: u-blox Neo-M8N GPS/GLONASS receiver; integrated magnetometer IST8310 Interfaces: 8-16 PWM outputs (8 from IO, 8 from FMU) 3 dedicated PWM/Capture inputs on FMU Dedicated R/C input for CPPM Dedicated R/C input for Spektrum / DSM and S.Bus with analog / PWM RSSI input Dedicated S.Bus servo output 5 general purpose serial ports 3 I2C ports 4 SPI buses Up to 2 CANBuses for dual CAN with serial ESC Analog inputs for voltage / current of 2 batteries Power System: Power module output: 4.9~5.5V USB Power Input: 4.75~5.25V Servo Rail Input: 0~36V Weight and Dimensions: Weight: 15.8g Dimensions: 44x84x12mm Other Characteristics: Operating temperature: -40 ~ 85°c Here 2 GPS receiver: Processor: STM32F302 Sensor Compass, Gyro, Accelerometer: ICM20948 Barometer: MS5611 Receiver Type: 72-channel u-blox M8N engine, GPS/QZSS L2 C/A, GLONASS L10F, BeiDou B11, Galileo E1B/C, SBAS L1 C/A: WAAS, EGNOS, MSAS, GAGAN Navigation Update Rate: Max: 10 Hz Positionaing Accuracy: 3D Fix Time to first fix: Cold start: 26s Aided start: 2s Reacquisition: 1s Sensitivity: Tracking & Navigation: -167 dBm Hot start: -148 dBm Cold start: -157 dBm Assisted GNSS AssistNow GNSS Online AssistNow GNSS Offline (up to 35 days) AssistNow Autonomous (up to 6 days) OMA SUPL& 3GPP compliant Oscillator: TCXO (NEO-8MN/Q) RTC crystal: Build in ROM: Flash (NEO-8MN) Available Antennas: Active Antenna & Passive Antenna Signal Integrity: Signature feature with SHA 256 Protocols & Interfaces: UART/I2C/CAN: JST_GH Main interface, Switch internally. STM32 Main Programming Interface: JST_SUR

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Unbranded
MPN	Does Not Apply
Model	Here 2
UPC	Does not apply
