Hf59b Professional High Frequency Emf Meter - Air-traffic Control Radar, Gsm, .

US $1678

montreal, QC, Canada
Feb 27th

Open on mobile:
QR code

RF Analyzer HFE59B is a professional kit based on the HF59B analyzer with an excellent dynamic response of approx. 93 dB. The innovative functions of the HF59B in combination with the broad frequency response of the UBB27 offers excellent outstanding possibilities for the evaluation of high frequency. Its functions and features are tailored to the needs and practical experiences of the building biology. Due to its relatively low price, it is often also used for scientific and industrial purposes. Set offer consisting of the HF59B and a wide range of accessories: Horizontal isotropic ultra broad bandwidth antenna UBB27_G3 from 27 MHz up to beyond 3.3 GHz (limited by the frequency response of the HF59B). 800 MHz high pass filter HP800_G3 for the suppression of low frequencies when measuring with the log.-per. antenna of the HF59B. High frequency preamplifier HV10_27G3. Increases the measurement range by 10 dB (by a factor of 10) – important when wanting to reduce the increased noise background in the radar or UMTS/3G-mode. Attenuator DG20_G3: Increases the maximum measurable value by 20 dB (or by a factor of 100) to 1999 mW/m? (= 1.999 W/m?). Plastic case K2 with shaped foam filler for a safe transportation of all components. Offers enough space for yet another Gigahertz Solutions measuring device (high frequency or low frequency). Characteristics Power flux density range: Power flux density: 0.001 – 1,999,000 µW/m? (i.e. 1 nanoW/m? nominal display resolution to 1.999 W/m? when applying the amplifier and attenuation module enclosed) Frequency range: 27 MHz – above 3.3 GHz Accuracy: Basic accuracy including linearity tolerance : +/- 3 dB Zero offset and rollover +/- 5 digits Sensor: 2 antennas: Optimized logarithmic periodic antenna with frequency compensation directly on the antenna: Less ripple, better directionality, improved shielding vs. ground, continuous LED-monitoring of quality of connections Quasi-isotropic ultra broadband ant Audio Analysis: Identification of pulsed radiation sources (mobile radio (GSM, UMTS/G3), cordless telephones (DECT), WLAN (Bluetooth), air-traffic control radar) by means of an acoustic signal proportional to the modulation frequency. Electric power supply: Rechargeable highpower 9.6 Volt NiMH battery pack inside the meter, average operation time: 7 – 8 hours Low-Batt. indication, auto-power-off. AC-adaptor for charging and long-term-operation included. Signal Rating: Display of peak value, peak hold as well as average value (switchable). A quantitative differentiation between pulsed and non-pulsed radiation – a unique feature within the broadband measuring technology. Outputs: A calibrated extra AC-measurement output for the demodulated signal, and a DC-output
