Hi-accuracy 0.1% Lcr Meter Dc Bias Lcrzdqg ? Deg Rad Test 200khz 5'' Tftlcd Usb

US $1,275.00

Shenzhen, China
Jun 9th

Open on mobile:
QR code

U2816B Features: 1. Four different parameters displayed simultaneously, flexible and comfortable combination 2. High speed and efficiency measurement: fastest 65 times / sec (including display) 3. Built-in typical DC bias: 0V/1.5V/2.0V/4.0V/5.0V 4. Independent and Low-noise DC source: -10V - +10V continuously adjustable, Resolution: 2.5mV 5. Automatic DUT trigger function: Plug & Measure, results and discriminant single displayed 6. Flexible limit comparator: tolerance mode, sequence mode and parameters exchange 7. Multi-parameter comparison test function, quickly and easily distinguish devices pass/fail 8. Powerful list sweep function: variety of different parameters and excitation sources can be mixed sweep test and displayed 9. RS232C/USB-CDC/USB-TMC/HANDLER/GPIB interface (optional) 10. 500 groups of setting for storage/recall Specifications Test Parameters |Z|,C,L,R, X, |Y|, B, G, D, Q, ? Basic Accuracy 0.1% Measuring Speed Fast: 65, Medium: 10, Slow: 5 (meas/sec) Equivalent Mode Serial, Parallel Ranging Mode Auto, Hold Trigger Mode Internal, Manual, DUT, External, BUS Correction Function Open/Short/Load List sweep 10 points frequency, level, DC bias, DC source Display type 480x272, 5-inch TFT LCD Memory 100 groups and 500 groups(USB disk) Test Signal Test Frequency 50Hz - 200kHz, 37 points Output Impedance 10?, 30?, 100? Test Level 10mV - 2V,Resolution: 1mV Internal DC Bias 0V/1.5V/2.0V/4.0V/5.0V Output DC Source -10V - +10V, Resolution: 2.5mV Measurement Display Range |Z|, R,X 0.01m? - 99.9999M? |Y|, G, B 0.0001uS - 999.999S C 0.00001pF - 9.99999F L 0.00001µH - 99.9999kH D 0.00001 - 9.99999 ?(Deg) -179.9° - 179.9° ?(Rad) -3.14159 - 3.14159 Q 0.01 - 99999.9 ?% -999.99% - 999.99% Comparator and Interface Comparator 10 bins, BIN0 - BIN9, NG,AUX PASS/FAIL LED displayed Interface RS232C/USB-HOST/USB-CDC/ USB-TMC/HANDLER/GPIB (Optional) Standard Accessories: U26005 4 terminal test fixture U26011 4 terminal Kelvin test clip leads U26010 Gilded shorting plate Optional accessories: U26006 Axial component test fixture U26008 SMD test fixture U26009 SMD Kelvin test tweezers U10501 1A DC bias board U10502 100mA DC bias board U10503 DC source board, -10V - +10V U10301 GPIB interface U10201 PC communication control software Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm different shipping charges before you order.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	U2816B
Country/Region of Manufacture	China
MPN	U2816B
Brand	generic
UPC	Does not apply
