Hickok 800 800a Testing Data Only: Rollchart Obsolete European Ca-4 Ca-5 Western

US $11.95

  • Orange Park, Florida, United States
  • Jan 29th
Open on mobile:
QR code
The only difference between the Hickok 800 and 800A is that the 800A has one extra tube socket for testing Compactrons. The two models use the same testing data. This is a compilation of all five testing data booklets plus supplements.The first section (23 pages) is a copy of the last roll chart for the 800A released by Hickok just before they went out of the tube tester business. I don't have the code number, but it is stamped November 7, 1989.  Next is a 3 page supplement covering new tubes not in the roll chart, mostly Compactrons. It has the code number 3200-325S. Then there are two pages of very hard-to-find testing data for Western Electric tubes.  The next section (24 pages) is the "Obsolete Tube" listings, code number 3200-159, which are the older tubes left off the latest roll chart.  The next section (26 pages) is the foreign tube data, code number 3200-253. Here are written in the American and other foreign numbers for many of the tubes. There are often several European numbers for the same tube.  Next there is the10 page test data booklet #3200-105 for testing tubes using the CA-4 socket adapter. Last is the 12 page test data booklet #3200-203 for testing tubes using the CA-5 tube adapter.All of my manuals are scanned on a high end 11x17" scanner, cleaned up in Paint.net, and printed on a business class laser printer. First Class postage in the USA is free. Foreign bidders are welcome, but please do not ask me to falsify customs documents. Payment via PayPal is expected within 3 days. Please see my other auctions for lots of great manuals. On Oct-16-02 at 04:39:31 PDT, seller added the following information: Pay me securely with any major credit card through PayPal! Posted with the eBay Android app
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Product Type Manual
