High Integrated 3axis Professional Tb6600hg Cnc Router Lathe Stepping Driver Set

US $138.99

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

{{{TBR_DOMAIN_NAME}}} eBay Item High Integrated 3Axis Professional TB6600HG CNC Router Lathe Stepping Driver Set SAVEBASE is a customer satisfaction oriented online business company supplying you with the best valued and affordable accessories and parallel devices for your personal digital equipments.Enjoy peace of mind shopping experience with us. © SAVEBASE.com All Rights Reserved Only USD +P&P USD* More.. Product Info Jump to :: Specifications :: What's in the Box Description I. About the 3rd Generation TB6600HG Stepper Controller This TB6600HG Stepper Controller has all the functions of TB6560AHQ Stepper Controller, and is specially developed for stepper motors with higher currents. All the 2 or 4 phase Nema17, Nema23, Nema24 stepper motors with current range of 0.2A~5.0A work perfectly with this TB6600HG Stepper Driver. It has standard version and professional version to meet different user needs. For further information, please click on the following links. Comparison between TB6600HG and TB6560AHQ Chipset. Details about TB6600HG Chipset. II. Standard Version VS Professional Version Functions Standard Version Professional Version Intelligent motor control via PC Manual motor control via control panel Intelligent switch between PC and control panel Synchronous coordinates display on PC and display panel Real-time tracking of motor moving path Aluminum & high intensity PVC housing protection Automatic G-code recording Manual G-code programming III. Two Unique Functions of Professional Version Automatic G-code recording function With the embedded intelligent memory chip, this stepper driver can easily record MAXIMUM 3 Axis' (X,Y,Z Axis) G-code running in the CNC software (e.g. Mach3, EMC2, KCAM4, etc.) on the computer, after which you can run motors using the recorded G-code without computer. Manual G-code programing function The upgraded built-in manual control tools (display panel and control panel) can not only be used for manual motor control, but also manual G-code programming. Manually programmed G-code will be recorded onto the embedded intelligent memory chip, after which you can easily run motors with recorded G-code. This function is widely applied in RBI machine, Conveyor etc. This package is 3 Axis Professional Version (TB3H-CD-P (Box)); If you need the standard version, please refer to our related item or simply contact us. PCB Instructions & Specifications Display Panel & Control Panel Features High performance, cost-effective; Manual motor control via control panel; support tool-settings on X, Y, Z axis without computer; Automatic identification and intelligent switch between computer and control panel; Synchronous coordinates display on computer and display panel, up to 3 axis (X, Y, Z axis); Real-time tracking of motor moving path; Automatic G-code recording for motor control; Manual G-code programming for motor control without computer; 1, 2, 4 (new mode), 8, 16 adjustable microstep control for more accurate and smoother motor running; Two-stage signal processing, smooth signal transmission; Automatic idle-current reduction, powerful anti-jamming capability; Overload, overcurrent, overvoltage, overheat protection; 5 types of input control on manual control interface, to set Limit, Estop, Midpoint-Setting, Cutter-presetting/Tool-Setting etc. Four types of output current adjustable; With 0-10V PWM signal output port for speed adjustment and one relay control port; Aluminum & high intensity PVC Box Design for better cooling effect and item protection; Compatibility with Mach2, Mach3(Recommended Software), Linux CNC (EMC2), KCAM4 CNC Software, etc. Suitable for 2 or 4 phase stepper motors with 0.2A~5.0A rated current. Applications For processing various pattern mould. For designing of brand, architecture mould, badge, nameplate, display boards, doorplate, furniture decoration in advertising industry. For carving portrait, scenery, handwriting, sealing, etc. Suitable for any small-and-medium automatic equipments with CNC controller, such as X-Y-Z tables, labeling machines, laser cutters, engraving machines, and pick-place devices. Dip Switch Settings Microstep Mode SW1 SW2 SW3 Output Current SW4 SW5 SW6 N/A ON ON ON 0.2A ON ON ON 1(Full Step) OFF ON ON 0.6A OFF ON ON 2 ON OFF ON 1.2A ON OFF ON 2 OFF OFF ON 1.8A OFF OFF ON 4 ON ON OFF 2.5A ON ON OFF 8 OFF ON OFF 3.3A OFF ON OFF 16 ON OFF OFF 4.2A ON OFF OFF N/A OFF OFF OFF 5.0A OFF OFF OFF Power Supply Selection Voltage Selection: 12-24V DC power supply for Nema 17 stepper motors 24-36V DC power supply for Nema 23/24 stepper motors 36-45V DC power supply for Nema 34 stepper motors (High (≥ 45V) voltage will burn out the chips or stepper motors!!! Please be careful in choosing power supply.) Current Selection: Output current of the power supply can be calculated by the following formula: Output current = Rated current of your stepper motors x quantity + 2A (For example, for driving 3 x 2A Nema 23 stepper motors, theoretically 24V 8A DC power supply is recommended, but higher power such as 24V 10A/15A will also be good. If you are not sure about the selection of power supply, please feel free to contact us.) Please SHUT DOWN the power before you plug or unplug the connectors to avoid burning up the board. Connection Diagram For Reference Specifications Specifications Input voltage 12V~45V (Peak) DC Output current 0.2A~5.0A (Peak) Drive type Pulse + Direction + Enable Signal Control (Bipolar constant-current PWM output) Suitable motor Nema17, Nema23, Nema24 (Rated current: 0.2A~5.0A) Total weight Approx. 650g Dimensions 177x147x46mm Operating Environment Cooling Natural Cooling or Fan Forced cooling Operating Environment Environment Avoid dust, oil fog, corrosive gas Ambient Temperature 0 °C - 50 °C (32 °F-122 °F ) Humidity 40%RH - 90%RH Operating Temperature 70 °C (158 °F) Max Storage Temperature -20 °C - 65 °C (-4 °F-149 °F) What's In We sell items to most countries of the world. For cost saving purpose, we can't keep a lot of stock for every item in every location. Your order with us may be sent from anyone of our dispatch centers that has sufficient in stock quantity. There is no extra charge for such a delivery service. Typical delivery durations(for reference only) are: Estimated Delivery Time (Airmail Packets) UK, Australia, New Zealand, South Asia, East Asia 10-15 business days USA, Canada, other EU countries(France,Germany, etc.) 10-18 business days Italy, Spain 20-30 business days South America, Other Countries 15-20 business days Please DO CONTACT and confirm with us before you bid IF you: - need the item urgently. - require that the item should be shipped from a specific city. - require that the item to be delivered within a certain period. - have any other questions/requirements about delivery. Remarks: *Your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notifications will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *Most parcels will be shipped by Airmail packets, it is not guaranteed that parcel should arrive within the time stated above.However, 95% parcels will be delivered within the reference time. *It is not possible to track airmail parcels' locations over the internet. We will help you to track orders if there are problems with them. *You will get the combine shipment discount automatically when checking out. If you have any problem in getting that discount please contact us. * PayPal: We accept PayPal ONLY (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) Remarks: *Please send payment within 5 days after auction ended. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer one year warranty on all products purchased from us. If your item has any warranty issue please contact us for a satisfying solution. Remarks: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are not refundable. Agreement: By placing an order, you acknowledge that you have accepted the terms and conditions of sale.You are welcome to contact us with any questions.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HY
UPC	190080041366
MPN	100413601
