High Voltage Boost Converter 10-32v To 45v-390v 110v/220v Zvs Capacitor Charging

US $13.55

???, ???, China
Jun 9th

Open on mobile:
QR code

High Voltage Boost Converter 10-32V to 45V-390V 110V/220V ZVS Capacitor Charging Description: Module Name: High Voltage boost converter module Module Properties: non-isolated step-up module Input voltage: two input voltage range selectable, (jumper selectable through the back of the PCB, default setting 10-32V input) 1) 8V-16V input 2) 10V-32V input Input Current: 5A (MAX) Quiescent current: 15mA (12V step up to 50V, the higher the output voltage will increase the quiescent current) Output voltage: ± 45-390V continuously adjustable (the default output ± 50V. This module has regulator function, after adjusted output voltage is stable and unchanging, not with changes in input voltage changes) Output Current: 0.2A MAX (affected by input voltage and dropout voltage,the higher the output voltage, the smaller the output current) Output Power: 40W (peak 70W) Working temperature: -40°C ~ + 85°C(if temperature too high , please enhance heat dissipation) Operating frequency: 75KHz Conversion efficiency: up to 88% (affected by input voltage, output volage, current and dropout voltage ) Short circuit protection: Yes. (Input 10A fuse, at the output please do not short circuit arc, it may damage the electronic component, if you need please add power resistor in series for limiting) Overcurrent protection: Yes. (Input current exceeds 4.5A, reducing the output voltage) Overvoltage protection: Yes (Output voltage exceeds 410V, lowering the output voltage) Input reverse polarity protection: Yes (non-self-healing, reverse burning fuse, you have better not reverse it.) Installation: four 3mm screws Connection: solderless terminals output Module dimensions: 60(L)*50(W)*22(H)mm The capacitor charging time measured data: 470uF full charge to 390V time is 2 seconds 1000uF full charge to 390V time is 4 seconds 2200uF full charge to 390V time is 8 seconds 4700uF full charge to 390V time is 18 seconds note: The module output is high voltage, on people, animals have life-threatening, the course please pay attention to safety precautions. We are not responsible. Applications: the capacitor charging, guns power. the power supply for your electronic device, can set the output voltage value according to your system. voltage pressure test power, glow tube power. hunting, rodent. package: 1 pcs Shipping & Handling Policy · Generally, delivery time is 10-20 business days to USA, United Kingdom, Australia and 15-30 days to most other countries. · All orders will be processed within 48 hours from the date of payment .The delivery confirmation will be sent ebay message when your order is processed · We will make shipment according to the address you put on eBay, if you want us to ship items to a different address please contact us before making the payment. International Buyers Note: 1) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. 2) Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Payment Policy We accept Paypal only. Returns Policy · We always take customer service seriously and want you to be 100% happy with your shopping experience here. If you are unsatisfied with our item or service, then please follow the good eBay practice to contact us before leaving any feedback and return it within 14 days for a replacement or money back. · Please contact me before you return it. · Buyer is responsible for the shipping cost of return postage. · Shipping and insurance costs will not be refunded. · We are committed to resolve all issues in a friendly and satisfactory manner. Contact us: If you have any problems, we are very glad to help you. We are handling large volume emails every day. Please allow us to reply your email within 24hrs Feedback: · Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us a positive feedback . When you rate the shipping time part please take international transit into consideration. · Your recognition will make us more confident to develop business and serve you better. · Our goal is to make sure you are a happy buyer and pleasant shopping with us. · Please email us before leaving any 1 or 2 ratings, negative feedback or open any dispute. · We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. thank you !
