High Voltage X-ray Machine Tube Trippler Multiplier Diode Board Assembly 75KV, US $45.00 – Picture 0
High Voltage X-ray Machine Tube Trippler Multiplier Diode Board Assembly 75KV, US $45.00 – Picture 0

High Voltage X-ray Machine Tube Trippler Multiplier Diode Board Assembly 75kv

US $45.00

  • La Valle, Wisconsin, United States
  • Jan 29th
Open on mobile:
QR code
This is the rectifier/trippler for the X-ray transformers in my other listings. The components are designed in a syncro rectifier configuration at 75KV, but can be re-arranged to make a up to 120KV as a Crokholft Walton multiplier. Just what you need for some really high voltage experiments!  I have lots of laser and other unique stuff for sale this week.
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Cleanly pulled part, Tested to work.”
