Hitachi Nes1-004lb 1/2hp 3-phase In 3-phase Out 200-240volt 3-phase Input Only

US $129.35

Sheboygan, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

NES1-004LB Inverter, 200-240 volt, 3 phase, 1/2 HP, 2.6 Amps (THIS MODEL REPLACES THE NOW DISCONTINUED X200 VERSION) This is the 3-PHASE INPUT ONLY VERSION. For the Single Phase Input ("phase converter") Version of this drive Please See The "SB" Series Inverters in Our Store When In doubt... always choose the next larger size inverter. Size the Inverter to the Amps of your motor... Not just the Horsepower Designed for excellent performance and user friendliness. Detailed Srecifications Can Be Viewed By Clicking On The Following Links Below :: (REPRESENTATIVE PHOTOS OF THE NE-S1 Series Inverters) 1-phase 200V 0.2 - 2.2kW 3-phase 200V 0.2 - 2.2kW <NE-S1 Series>Quick Referende Guide(PDF format,2.17MBytes) (Display new window) Standard Specifications Dimensions Operation and Programming Main Circuit Terminals Control Circuit Terminals Protective Functions Features Point 1. Space Saving Point 2. Simple Operation Point 3. Global Standards Point 4. Inherent Functions to achieve energy savings Model Name Indication Model Configuration Space saving Among the Smallest Form-Factors in their Category 43% smaller than equivalent X200 (0.2kW) Side by side installation to save panel space Note *Side-by-side installation: derating for carrier frequency and output current required no space between To Page Top Simple Operation RUN/Stop/Rest is integrated in one button for simple operation. Full function attachable operator available as an option. Standard Operator Option Operator To Page Top Global Standards Conformity to global standards(conforms to CE/UL/c-UL/c-Tick)Compatible to both sink and source as standard. (logic input is compatible with both sink and source logic.)RS485 Modbus-RTU communication port is standard.To Page Top Inherent Functions to achieve Energy Savings Automatic energy saving function is implemented to minimize energy consumption Arithmetic .operation and delay functions Keypad / Terminal Switching 2nd motor function Three wire Operation Function Analog Input Disconnection Detect Function Note *Parameter change and setting by keypad etc. Product Inquiry Catalog download (Product catalogue is avaible in PDF format) Three-phases 200V class Models NES1- 002LB 004LB 007LB 015LB 022LB Applicable Motor Size*1 kW 0.2 0.4 0.75 1.5 2.2 HP 1/4 1/2 1 2 3 Rated Outout capacity (kVA) 200V 0.4 0.9 1.3 2.4 3.4 240V 0.5 1 1.6 2.9 4.1 Rated input voltage (V) Three phases 200V –15% to 240V +10%, 50/60Hz ±5% Rated output voltage (V) Three phases 200 to 240V (corresponding to input voltage) Rated output current (A)*2 1.4 2.6 4 7.1 10.0 Cooling Method Self cooling Force Ventilation Braking Torque *3 (capacitor feedback ) Appx. 50% Appx. 20 to 40% Weight (kg) 0.7 0.8 0.9 1.2 1.3 To Page Top Single-phase 200V class Models NES1- 002SB 004SB 007SB 015SB 022SB Applicable Motor Size*1 kW 0.2 0.4 0.75 1.5 2.2 HP 1/4 1/2 1 2 3 Rated Outout capacity (kVA) 200V 0.4 0.9 1.3 2.4 3.4 240V 0.5 1 1.6 2.9 4.1 Rated input voltage (V) Single phase 200V –15% to 240V +10%, 50/60Hz ±5% Rated output voltage (V) Three phases 200 to 240V (corresponding to input voltage) Rated output current (A)*2 1.4 2.6 4 7.1 10.0 Cooling Method Self cooling Force Ventilation Braking Torque *3 (capacitor feedback ) Appx. 50% Appx. 20 to 40% Weight (kg) 0.7 0.8 1.0 1.2 1.3 To Page Top General Specifications Item Specificattion Enclosure *4 IP20 Control Control Method PWM Output Frequency Range *5 0.5 to 400Hz Frequency Resolution *6 Digital command: ±0.01%, Analog command: ±0.2% (25 ± 10°C) Frequency Setting Resolution Digital: 0.1Hz, Analog: (max frequency)/1000 Voltage/Frequency Characteristics V/f control,V/f variable (constant torque, reduced torque) Overload Capacity 150% for 60 sec. Accel./Decel. Time 0.00 to 3000 sec. (linear, sigmoid), two-stage accel./decel. Carrier Frequency Range 2.0 to 15.0 kHz Protective Functions Over-current, Over-voltage, Under-voltage, Overload, Overheat, Ground fault at power-on, Input over-voltage, External trip, Memory error, CPU error, USP error, Driver error, Output phase loss protection Input signal Frequency setting External signal*7 0 to 10 V DC or 4 to 20 mA, RS485 interface (Modbus RTU) Operator keypad(Option) Up and Down keys / Value settings or analog setting via potentiometer on operator keypad FW/RV Run Operator Keypad(Option) Run key / Stop key(change FW/RV by function command) External signal FW Run/Stop(NO contact), RV set by terminal assignment(NC/NO), 3-wire input available Serial port RS485 interface (Modbus RTU) Intelligent Input 5 terminals Analog Input 1 terminal( O/OI terminal:Voltage Input 10bit/ 0 to 10V, Current input :10bit/ 0 to 20mA selectable with switch) Output signal Intelligent output terminal 1 terminal Intelligent Relay Output 1c output 250V AC/ 30V DC 2.5A relay (AL0, AL1, AL2 terminals) Moniter output terminal 1 terminal Communication RS-422 RJ45 connector (common to RS485: selectable with switch) For External Keypad, for ProDriveNext RS-485 RJ45connector (common to RS422, selectable with switch) Modbus-RTU Other Function AVR (Automatic Voltage Regulation), V/f characteristic selection, frequency upper/lower limit, 8 stage multispeed, Start Frequency Adjustment, Jogging, Carrier Frequency Adjustment, PID control, frequency jump, external frequency input bias start/end, S-curve and linear Accel/Decel, DC braking, Electronic Thermal characteristics and level adjustment, retry function, Torque Boost, trip history, Software Lock Mode, Frequency, Scaling Conversion Factor setting, USP function, 2nd motor control, UP/DOWN, OC suppression etc Environment, etc Operating Temperatu 10 to 50°C (derating is neeeded for 40°C and over) Strage Temperature 20 to 65°C (during short period for transportation) Humidity 20 to 90% RH Vibration 5.9mm/s2 (0.6G) 10 to 55Hz Location Altitude 1,000 m or less, indoors (no corrosive gasses or dust) Color Black Standards UL, CE, c-UL, c-tick Option Remote operator with copy function (WOP), Remote operator (OPE-SRmini, OPE-SR), Operator (NES1-OP), input/output reactors, DC reactors, radio noise filters, LCR filter, communication cables (ICS-1, 3) To Page Top Note *1The applicable motor refers to Hitachi standard 3-phase motor (4-pole). When using other motors, care must be taken to prevent the rated motor current (50/60 Hz) from exceeding the rated output current of the inverter.*2The output voltage decreases as the main supply voltage decreases (except when using the AVR function). In any case, the output voltage cannot exceed the input power supply voltage.*3The braking torque via capacitive feedback is the average deceleration torque at the shortest deceleration (stopping from 50/60 Hz as indicated). It is not continuous regenerative braking torque. The average decel torque varies with motor loss. This value decreases when operating beyond 50 Hz.*4The protection method conforms to JIS C 0920(IEC60529).*5To operate the motor beyond 50/60 Hz, consult the motor manufacturer for the maximum allowable rotation speed.*6The output frequency may exceed the maximum frequency setting (A004 or A204) for automatic stabilization control.*7DC 4 to 20 mA Input, need parameter setting by Keypad etc. Analog input voltage or current can be switched by switch as individually and not use them in the same time. Inverter : NE-S1 Series : Dimensions *Please click to open a new window.NES1-002LB~007LB, NES1-002SB, NES1-004SB NES1-015LB, NES1-022LB, NES1-007SB~022SB NE-S1 Standard Operator Panel To Page Top Exclusive use Operator Panel (Option) To Page Top Keypad Navigation Map . ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Error Signal Over Current Trip (Blink & Lighting(1sec)) Over Voltage Trip (Same Blink (1sec)) Under Voltage Trip (Alternate Blink (1sec)) Over Load Trip (Same Lighting) Major Failures*1 (Light Out & Lighting) Other Failures (Light Out & Blink(1sec)) Note *1The Major fault: When a memory error, CPU error, Ground fault, Output phase loss protection error and Driver error. ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ WE CAN QUOTE ANY OF HITACHI'S INVERTERS... Any Model, Size, Voltage, Accessories, ECT... JUST ASK FOR A QUOTE BUY WITH CONFIDENCE !!! WE ARE AN AUTHORIZED HITACHI DEALER WITH 100% CUSTOMER SATISFACTION. ALL DRIVES ARE BRAND NEW WITH FULL HITACHI FACTORY WARRANTY ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ S H I P P I N G FREE SHIPPING: TO CONTINENTAL 48 States Using Fed-Ex or UPS Ground. INTERNATIONAL SHIPPING: Contact us for a quote - We charge actual shipping cost only EXPEDITED SHIPPING: Overnite, Next Day Air or other shipping options are available ~ Contact us for options/shipping quote We can also ship items on your Fed-Ex or UPS account if you would prefer ITEMS THAT WILL BE SHIPPED OUTSIDE THE U.S. NEED TO HAVE A NON-PROLIFERATION CERTIFICATE FILLED OUT BEFORE WE CAN SHIP THE ITEM ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Any Questions Don't Hesitate To Ask. We can get you the information you need. Visit Our e-bay Store: http://stores.ebay.com/motors-drives Thanks For Looking !!! ..

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Brand New In Factory Sealed Box! - With Factory Warranty!”
