Hmi/ami-presco 1205 Solder Paste Stencil Printer Smt Circuit Board Semi-auto

US $8,277.00

Santa Fe, New Mexico, United States
Jan 30th

Open on mobile:
QR code

HMI/AMI-Presco 1205 Solder Paste Stencil Printer for SMT This is a refurbished Hary Manufacturing, Inc. (HMI) / AMI-Presco model 1205 semi-automatic stencil printer. Perfect for prototype and small production volume stencil printing. Includes Refurbished model 1205 screen printer DS-II pneumatic dual squeegee head 2) 10.5 inch squeegees Stand Micromonitor - Squeegee Speed Display and Cycle Counter Internal vacuum generator Blank stage plate 19x18 inch plastic stage plate cover Stencil frame mounting plate with 15x13 inch opening Operator's manual Features Manual XYθ Stage Positioner Vertical lift Stencil leveling screws 3-point kinematic mounting of stencil frames for fast, repeatable swapping Aqueous hydraulic squeegee drive for speeds of 0.5 - 10 in/s (13-254mm/s) Pneumatic reciprocating carriage drive Contact / Off-Contact Print Modes Applications FR-4 board material Fine pitch SMT Flex circuit materials Ultrafine pitch SMT LTCC (Low Temp Co-fired Ceramics) TSOP (Thin Small Outline Packages) Ceramic substrates Ball Grid Array (BGA) Flat panel displays Direct Chip Attach (DCA) Micro Via Flip-Chip packages General solder deposition XYθ Micrometer Positioner The precision stage positioner utilizes three micrometers for adjustment. True theta movement is about center of the stage. Both X and Y movements offer 1 inch of travel. A unique system of using vacuum for stage locking once proper alignment has been achieved and air bearing levitation during adjustment to ensure long life with minimal wear. The precision stage is mounted on a reciprocating carriage which is driven by a time-tested and proven air cylinder and Thomson rod assembly with physical hard stops at both limits. HMI guarantees consistent and repeatable positioning of the carriage to ±0.0005 inch. Programmable Squeegee Drive This printer incorporates an Aqueous Hydraulic squeegee drive system which provides smooth squeegee motion adjustable up to 10 in/s and is independently set for each print direction. A smooth steady print stroke without vibration or chatter is achieved by the direct mount drive assembly of either system. Print Head The DS-II dual squeegee print head offers pneumatic squeegee pressure control also with micrometer adjustable squeegee down stop or flood blade position. Squeegee blade angle of attack and squeegee leveling on either print head is fully adjustable. Squeegee to substrate leveling is accomplished through the use of a manual micrometer adjustment. The DS-II print head can accept two traditional style squeegees or two metal squeegee blades can be installed for stencil printing applications. The DS-II can also accept a single squeegee and a stainless steel flood blade. Calculate Freight Specifications Maximum Substrate Size 13x16 in Maximum Print Area 12x14 in Air Supply Connection 1/4 inch NPT Maximum Stencil Frame Outer Dimensions 19x18 in Minimum Air Pressure 85 psig Air Flow 6 ft3/min AC Power 115 V Retail Price $47,770.00 Inspection by a Hofstra Group technician allows us to guarantee this hardware to perform to your satisfaction. This item carries a 7-day unconditional right of return and a 90-day warranty. In the unlikely event that you need to return it, we will arrange and pay for return shipping in addition to refunding the purchase price and original shipping. Please review our Sales Agreement for more information. _gsrx_vers_586 (GS 6.8 (586))
