Honeywell R8182h1070 Combination Protectorelay & Hydronic Heating Control

US $458.57

Waterbury, Connecticut, United States
Feb 24th

Open on mobile:
QR code

Store Home About Us Contact eBay Profile Feedback Browse Categories Store Home Bathroom Kitchen Faucets & Trims Plumbing Supplies Heating Supplies HVAC & Air Quality Pumps Thermostats Tools Boilers Water Heaters Valves Honeywell R8182H1070 Combination ProtectoRelay & Hydronic Heating Control Brand: Model: R8182H1070 Model Number: R8182H1070 $465.22 $1,146.43 You Save: $642.44 (138.1%) Follow Us: Product Description Immersion type Aquastat controller and oil burner primary control provides high limit and low limit/circulator control for oil-fired hydronic heating systems. Product Features Use in intermittent ignition applications. Capable of zone control with zone valves. Circulator zone control with ZC and ZR terminals. Flame failure during the running cycle results in a 45 second attempt to restart. If unsuccessful, safety shutoff occurs, requiring manual reset before burner can be restarted. J mount on 4 x 4 in. junction box and include 5 ft (1.5 m) armored capillary with remote sensor. C554A Cadmium Sulfide Flame Detector and a 24 Vac thermostat required. Temperature Range: High Limit-- 130 F to 240 F; Low Limit-- 110 F to 220 F Differential: High limit: 10 F fixed; Low limit/circulator: 10 F to 25 F adj. Categories Bathroom Kitchen Faucets & Trims Plumbing Supplies Heating Supplies HVAC & Air Quality Company About Plumbing Planet Contact Us Our Policies eBay Profile Feedback Connect With Us Facebook Twitter Pinterest YouTube © Copyright 2012-2014 Plumbing Planet. All Rights Reserved.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	R8182H1070
Operating Temperature	High Limit:130 To 240 deg F, Low Limit: 110 To 220
Type	Combination ProtectoRelay? & Hydronic Heating Cont
Differential Temperature	High Limit: 10 deg F Fixed; Low Limit/Circulator:
Mounting	Standard 4 Inch x 4 Inch Junction Box
Switch Action	SPDT
Temperature Rating	Maximum 250 deg F At Element
Power Consumption	9 watt
Dimensions	7-1/8 Inch Height x 5-1/4 Inch Width x 3-7/16 Inch
UL Listed	Yes
Standards	UL File No. MP268, Vol. 37, Sec. 1, CSA File No. L
CSA Certified	Yes
Electrical Ratings	Ignition: 360 VA, Burner: At Full Load - 4.4 amp A
Hazmat Information	UN1294 Toluene
Humidity Range	0 To 95 PCT RH (Non-Condensing)
UPC	085267078399
