Horizon Ht-70 Three Knife Trimmer

US $3800

Philadelphia, Pennsylvania, United States
Jun 9th

Open on mobile:
QR code

1996 Horizon HT-70 Three Knife Trimmer The Horizon HT-70 is a three knife trimmer that can be used in-line or off-line. It is a high capacity trimmer that cycles at 1,000 books per hour. The max capacity for an untrimmed book is 12.99" x 12.99". For trimmed books, the max is 11.81" x 11.81". HT-70 Major Specifications Untrimmed Book Size Max. 330 x 330 mm (12.99” x 12.99”) Min. 148 x 105 mm (5.83” x 4.14”) Trimmed Book Size Max. 300 x 300 mm (11.81” x 11.81”) Min. 142 x 100 mm (5.60” x 3.94”) Trim Thickness Max. 50.8 mm (2.0”) Standard Size Trimmed by Standard Accessory A4T / A4Y / A5T / A5Y / A6T / B5T / B5Y / B6T (T: Portrait, Y: Landscape) Clamp and Pressure Hydraulically Operated Steplessly variable adjustment within the range from 1.5 to 9.8 kN (150 to 1,000 kgf) Production Speed Max. 800 cycles/hr. (A4T) Table Height 865 mm (34.0”) Voltage / Frequency 3-Phase 200 V, 50 / 60 Hz 3-Phase 220 / 240 V, 60 Hz 3-Phase 380 / 400 / 415 V, 50 Hz Rated Current 200 V, 50 / 60 Hz, 8.9 / 8.5 A 220 V, 60 Hz, 9.7 A 240 V, 60 Hz, 7.0 A 380 V, 50 Hz, 6.3 A 400 / 415 V, 50 Hz, 6.0 A Power Consumption 200 V, 50 / 60 Hz, 1.2 / 1.6 kW 220 V, 60 Hz, 2.85 kW 240 V, 60 Hz, 2.19 kW 380 / 400 / 415 V, 50 Hz, 3.3 kW Heat Output 3,190 kJ (760 kcal) Motors 1.5 kW x 1 / 0.75 kW x 2 / 60 W x 1 / 25W x 1 Machine Dimensions 1,160(W) x 2,260(D) x 1,600(H) mm (45.7” x 89.0” x 63.0”) Noise Level LA peak : 91.1 dB / LAeq : 77.9 dB Machine Weight Main Body : 1,530 kg (3,373 lb.) Compressor : 53 kg (116 lb.) Northern Machine Works Northern Machine Works is a distributor of binding and finishing equipment and supplies . We have over 110 years of experience, and a qualified team of professionals to assist you with all your equipment, supply and service needs. Northern has it's own service department to provide field service support. We can handle mechanical, electric and electronic service needs. In addition to Northern's own service staff we are also a member of the Bindrite Dealer Association to provide service on a national basis. Shipping Policy Shipping and Freight is available. We will crate the machine and place in on a skid ready for pickup. If you wish, we can arrange shipment at a additional cost. Please ask about shipping costs. We take credit or certified check.
