Hot Usb To Ttl Serial Ch340t Isp Download Module

US $1.69

??, China
Jan 29th

Open on mobile:
QR code

USB to serial CH340T ISP download module USB to TTL Product Description USB to serial new upgrade ! A change is not compatible with earlier versions of PL2303 WIN7 problem solving using CH340T chip system compatibility issues. Using high- quality materials , double-sided PCB board blue oil , good quality , convenient and practical pin interface leads . Note : C5 is itself does not require soldering , welding is not missing , do not worry ~ ~ USB to serial port, can replace the MAX232, leads to 51 single- copy program interfaces are +5 V, +3.3 V, GND, TXD, RXD. When used, the driver needs to be installed CH340T can only download the program , go after the driver took our websitesochange.cnTo download . Only three pins using a USB to serial , namely GND, TXD, RXD GND with microcontroller GND, TXD RXD connected microcontroller that P3 ^ 0, RXD TXD connected microcontroller that P3 ^ 1 Special note: We sent out each one is tested , here to remind buyers do not get directly after the operation , so as not think there is a problem . First, do a simple test method is very simple : If you take the line plugged into the computer , the computer prompts "Found new hardware .... " Black pen then with a multimeter (GND), respectively, to pick up the red pen (RX) and (TX) can measure the voltage , then the small plates must be good. Special note here : If there is (GND) connected to the device pin voltage , power must burn , so the user before the connection must be measured accurately pin devices , so as to avoid unnecessary losses ! When used, the need to install drivers can only download the program . Be sure to look for before connecting to the pin definitions , especially GND must not be connected to the voltage of the pin , and the RX and TX side and do not pick up on the VCC pin , ( Actual measurement over some VCC pin voltage up to 14V.) Take the wrong turn will burn the chip wiring , must be careful not to take their own small plate experiment , otherwise we are not responsible for the burn . USB to serial port support win7 32 -bit, 64 -bit operating system, support win xp operating system. package include 1X USB to TTL module Contact us We will response to all enquiries with 24 hours(ASAP) but please allow delay response for non-business time. If you have any questions on the product you are interested or your want to order please do not hesitate to contact us. we accept the paypal only now We offer the Air mail (china POST)for default. It will not much slower than express(About 15-25 working days). If you prefer other ways of express for shipping, eg DHL, TNT, UPS, please contact us first. About the Shipping insurance: For other countries and areas, we also suggest buy the insurance while you paying. The insurance will be included the tracking number, that will make your parcel be registered and more safe. Furthermore, such parcels always be treated as a priority by POST OFFICE. Even it lost, we can get the compensation soon. Without it, both you and us can not follow the parcel, just wait... Delivery address on Paypal Only--We only ship to the given address in Paypal payment. Please make sure payment address in Paypal is correct. Any non-received items caused by invalid address registered on Paypal are not in our full refund or replacement policy. If you would like to change the address, please contact us IMMEDIATELY after your payment. Engineered for professional eBay sellers! On Jan-08-15 at 23:32:49 PST, seller added the following information:
