Hp 8484a Rf Power Sensor, Hp8481h Power Sensor,hp8496b Rf Attenuator

US $1,200.00

Salida, California, United States
Jan 29th

Open on mobile:
QR code

Up for sale is a set of RF test equipment used for measuring RF power. The set comes with an HP436A power meter, two(2) power sensors HP8484A and HP8481H, a 110 dB variable attenuator HP8496B, two(2) sensor cables, and the HP436A Service Manual. The items have been tested as shown in the pictures. Please take a look at the pictures for the actual description of the items. Here are some specs taken from the company's website: HP436A The Keysight 436A power meter is a general-purpose digital power meter intended for manual and automatic radio-frequency (RF) and microwave-power measurements. It is compatible with the entire series of 8480 power sensors. The 436A measures either absolute or relative power. It displays absolute power in either watts or dBm, and relative power in dB. The 436A offers intuitive and straightforward manual operation as well as optional GPIB programmability (Option 022). Display readings in Watts, dBm or dB relative eliminating measurement conversion Peaking meter for analog adjustments Cal factor to compensate each sensor for improved accuracy Frequency Range: 100 kHz to 110 GHz Power Range: -70 to +44 dBm Power Accuracy: ±0.5% Power Reference: Internal 50 MHz oscillator/Type-N output HP8484A HP 8484A High Sensitivity Power Sensor measures power from 0.1nW to 10 uW over a frequency range of 10MHz to 18GHz. It is furnished with the 11708A 50MHz reference attenuator for precise calibration with 1 mW power meter reference oscillator. Noise and drift have been reduced to less than 5% of full scale on the 300 pW range (only 15 pW) when it is used with the 435B power meter. Noise and drift are even less with the 436A, 437B and 438A power meters. HP8481H Agilent 8481H Power Sensor 10 MHz to 18 GHz, 100 uW to 3 W, Refurbished Compatible with the 435B, 436A, 437B, 438A, 70100A, E1416A, E4418A/B and E4419A/B power meters Excellent SWR for reducing mismatch uncertainty Precision type-N connector Agilent 8481H thermocouple power sensor is designed for use with the EPM series, EPM-P series, 70100A, E1416A and the 43x series power meters, and provides extraordinary accuracy and stability. The 8481H power sensor gives you extremely low SWR. HP8496B Key Features & Specifications Superior RF Performance Frequency range: dc to 18 GHz Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz Maximum SWR: 1.5 to 8 GHz, 1.6 to 12.4 GHz, 1.9 to 18 GHz Repeatability and Life Span Repeatability life: 0.03 dB max 5 million cycles per section, typical 5 million cycles per section Power handling Maximum RF input power: 1 W (average), 100 W (peak) Features Connector type: choice of Type-N female, SMA female, APC-7 Connect in series with 11716A Attenuator Interconnect Kit, Type-N Connect in series with 11716C Attenuator Interconnect Kit, SMA Description The Keysight 8496B dc to 18 GHz manual step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 10 dB steps from 0 to 110 dB. Precision gold-plated leaf springs ensure long life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps. Please read the description before purchasing, I will allow returns within 7 days due shipping mishandling. These are sensitive devices and can get easily damaged by an untrained user and so returns are not allowed. I have tested it before posting and can be seen on the pictures using a Wayne Kerr signal generator. Please see my feedbacks as I do not sell junks here. Thanks for watching.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	HP
Country/Region of Manufacture	United States
Model	436A,8484A,8496B,8481H
