Hp 8592l Spectrum Analyzer

US $3200

Keller, Texas, United States
Oct 28th

Open on mobile:
QR code

HP 8592L 22 GHz Spectrum Analyzer When you need a full-featured, frequency-accurate RF or microwave spectrum analyzer to meet your field or factory testing requirements the HP 8592L gives you the features and options you need to get the job done. Reliable and economical, the 8592L operates from 9 kHz to 22 GHz. with preselection starting at 2.75 GHz and an amplitude range of 114 dBm to +30 dBm. The HP 8592L is a low-cost, but full-featured, frequency accurate microwave spectrum analyzer designed to meet your general purpose measurement needs. The easy-to-use interface provides access to more than 200 built-in functions. Features Frequency counter: Eliminate the need for a separate frequency counter with the built-in frequency counter with ±2.1 kHz accuracy at 1 GHz (±7.6 kHz from 0 to 50 °C). Multiple resolution bandwidth filters: Optimize the tradeoffs of speed, sensitivity and the separation of closely spaced signals with your choice of 10 resolution bandwidth filters beginning at 1 kHz. 142 dB amplitude measurement range: Measures signals directly with -112 dBm to +30 dBm amplitude measurement range. One-button measurement routines: Save time, setup, and training with one button measurement routines such as Adjacent Channel Power, signal bandwidth and Third Order Intercept (TOI). Phase noise of 105 dBc/Hz at 30 kHz offset: Uncover small signals close to carriers with an internal phase noise that will not get in your way. Dual interfaces: Operate remotely and print directly with the optional dual interfaces that combine either an GPIB or RS-232 port with a parallel (Centronics) port. Built-in Measurement Capability Third-order intercept, percent AM, and N dB bandwidth are just a few of the built-in measurements. These measurements are performed at the press of a single softkey. Results are displayed onscreen. And the downloadable program (DLP) capability lets you write your own built-in measurements using the DLP editor and an external keyboard. Frequency counter Eliminate the need for a separate frequency counter with the built-in frequency counter with 2.1 kHz accuracy at 1 GHz (7.6 kHz from 0 to 50 ?C). Multiple resolution bandwidth filters Optimize the tradeoffs of speed, sensitivity and the separation of closely spaced signals with your choice of 10 resolution bandwidth filters beginning at 1 kHz. 142 dB amplitude measurement range Measures signals directly with -112 dBm to +30 dBm amplitude measurement range.
