Hp/agilent 33120a 15 Mhz Arbitrary Function Waveform Generator

US $1,094.99

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! HP/Agilent 33120A 15 MHz Arbitrary Function Waveform Generator Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from HP/Agilent and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is guaranteed to work for 30-days, parts and labor, excluding freight. The Unit's Serial Number Tag Reads: Serial Number: US36004089 Link to the Datasheet: HP/Agilent 33120A Generator Datasheet Link to the Quick Reference Guide: HP/Agilent 33120A Generator Quick Reference Guide Link to the Manual: HP/Agilent 33120A Generator User's Manual Link to the Service Manual: HP/Agilent 33120A Generator Service Manual Description: The 33120A function generator has a proven legacy, 15 MHz bandwidth, arbitrary waveforms & modulation capability. DDS technology provides precise adjustment and frequency stability. 15 MHz sine & square waveforms Ramp, triangle, noise & DC waveforms 12-bit, 40 MSa/s, 16,000 points arbitrary waveforms AM (int/ext), FM (int), FSK (internal/external), burst (int/extl) Linear & logarithmic sweeps and burst operation IntuiLink software plus GPIB & RS-232 interfaces included (we do not have the software but it should be downloaded from Agilent) Wavforms Specifications: Standard: Sine, square, triangle, ramp, noise, sin(x)/x, exponential rise exponential fall, cardiac, dc volts. Arbitrary: Waveform Length: 8 to 16,000 points Amplitude Resolution: 12 bits (including sign) Sample Rate: 40 MSa/s Non-Volatile Memory: Four (4) 16,000 waveforms Frequency Characteristics: Sine: 100 µHz - 15 MHz Square: 100 µHz - 15 MHz Triangle: 100 µHz - 100 kHz Ramp: 100 µHz - 100 kHz White Noise: 10 MHz bandiwdth Resolution: 10 µHz or 10 digits Accuracy: 10 ppm in 90 days, 20 ppm in 1 year, 18°C to 28°C Temp. Coefficient: < 2 ppm/°C Aging: < 10 ppm/yr Sinewave Spectral Purity Specifications: Harmonic Distortion: dc to 20 kHz: -70 dBc 20 kHz to 100 kHz: -60 dBc 100 kHz to 1 MHz: -45 dBc 1 MHz to 15 MHz: -35 dBc Spurious (Non-Harmonic): DC to 1 MHz: < -65 dBc 1 MHz to 15 MHz: < -65 dBc + 6 dB/octave Total Harmonic Distortion: DC to 20 kHz: < 0.04% Phase Noise: < -55 dBc in a 30 kHz band Signal Characteristics: Squarewave: Rise/Fall Time: < 20 ns Overshoot: 4% Asymmetry: 1% + 5 ns Duty Cycle: 20% to 80% (to 5 MHz), 40% to 60% (to 15 MHz) Triangle, Ramp, Arb: Rise/Fall Time: 40 ns (typical) Linaerity: < 0.1% of peak output Setting Time: < 250 ns to 0.5% of final value Jitter: < 25 ns Output Characteristics: Amplitude (into 50 Ω): 50 mVpp - 10 Vpp[1] Accuracy (at 1 kHz): ±1% of specified output Flatness (sinewave relative to 1 kHz): < 100 kHz: ±1% (0.1 dB) 100 kHz to 1 MHz: ±1.5% (0.15 dB) 1 MHz to 15 MHz: ±2% (0.2 dB Ampl > or = to 3 VRms. ±3.5% (0.3 dB) Ampl < 3 Vrms Output Impedance: 50 Ω (fixed) Offset (into 50 Ω)[2]: +5 Vpk ac+dc Accuracy: ±2% of setting + 2 mV Resolution: 3 digits, amplitude and offset Units: Vpp, Vrms, dBm Isolation: 42 Vpk maximum to earth Protection: Short circuit protected ±15 Vpk overdrive < 1 minute Modulation: AM: Carrier -3 dB Freq.: 10 MHz (typical) Modulation: Any internal waveform including Arb Frequency: 10 MHz - 20 kHz Depth: 0% - 120% Source: Internal/External FM: Modulation: Any internal waveform including Arb Frequency: 10 MHz - 10 kHz Deviation: 10 MHz - 15 MHz Source: Internal only FSK: Internal Rate: 10 MHz - 50 kHz Frequency Range: 10 MHz - 15 MHz Source: Internal only Burst: Carrier Freq.: 5 MHz max. Count: 1 to 50,000 cycles or infinite Start Phase: -360° to +360° Internal Rate: 10 MHz - 50 kHz ±1% Gate Source: Internal/External Gate Trigger: Single, External or Internal Rate Sweep: Type: Linear or Logarithmic Direction: Up or Down Start F/Stop F: 10 MHz - 15 MHz Speed: 1 ms to 500 s ±0.1% Trigger: Single, External, or Internal Rear Panel Inputs: Ext. AM Modulation: ±5 Vpk = 100% modulation 5k Ω input resistance External Trigger/FSK/Burst Gate: TTL low true System Characteristics[3]: Configuration Times[4]: Function Change[5]: 80 ms Frequency Change[5]: 30 ms Amplitude Change: 30 ms Offset Change: 10 ms Select User Arb: 100 ms Modulation Parmeter Change: < 350 ms Arb Download Times over GPIB: Arb Length: Binary: ASCII Integer: ASCII Real[6]: 16,000 points 8 sec 81 sec 100 sec 8,192 points 4 sec 42 sec 51 sec 4,096 points 2.5 sec 21 sec 26 sec 2,048 points 1.5 sec 11 sec 13 sec Arb Download Times over RS-232 at 9600 Baud[7]: Arb Length: Binary: ASCII Integer: ASCII Real[8]: 16,000 points 35 sec 101 sec 134 sec 8,192 points 18 sec 52 sec 69 sec 4,096 points 10 sec 27 sec 35 sec 2,048 points 6 sec 14 sec 18 sec General Specifications: Power Supply: 110 V/120 V/220 V/240 V ±10% Power Line Frequency: 45 Hz to 66 Hz and 360 Hz to 440 Hz Power Consumption: 50 VA peak (28 W average) Operating Environment: 0°C to 55°C Storage Environment: -40°C to 70°C State Storage Memory: Power Off state automatically saved, 3 User Configurable Stored States Interface: IEEE-488 and RS-232 Language: SCPI - 1993, IEEE-488.2 Dimensions: 254.4 mm W x 103.6 mm H x 374 mm D Weight: 4 kg (8.8 lbs) Safety Designed To: UL-1244, CSA 1010, EN61010 EMC Tested To: MIL-461C, EN55011, EN50082-1 Vibration and Shock: MIL-T-28800, Type III, Class 5 Acoustic Noise: 30 dBa Warm-Up Time: 1 hour Notes: 1: 100 mVpp - 20 Vpp into open circuit 2: Offset < or = to 2x pk - pk amplitude 3: Times are typical. May vary based on controller performance 4: Time to change parameter and output the new signal. 5: Modulation or sweep off 6: Times for 5-digit and 12-digit numbers 7: For 4800 baud, multiply the download times by two; For 2400 baud, multiple the download times by four, etc. 8: Time for 5-digit numbers; for 12-digit numbers, multiply the 5-digit numbers by two For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Side View Picture 5 - Serial Number For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $25.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 05/06/14 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Unit is fully tested and guaranteed to work for 30-days, parts and labor, excluding freight.”
