Hubbell Hbl2731 Locking Plug 3p/4w 480 Volt 30 Amp Three Phase Nema L16-30p T37

US $160

  • Mount Vernon, Iowa, United States
  • Jun 8th
Hubbell HBL2731 Locking Plug  Listing Includes (1) Hubbell HBL2731 Locking Plug 3P/4W 480 Volt 30 Amp Three Phase NEMA L8-30. Free Shipping Included! Product Item  Plug  Wiring Scheme  3-Pole, 4-Wire Grounding  Amperage  30A  Voltage  3 Phase 480V AC  NEMA Configuration  L16-30P  Item Style  Insulgrip  Device Color  Black/White  Horsepower  10  Cord Dia.  .35"-1.15" (9-29)  Blade Holder Material  Natural White Nylon  Terminal Retainer Material  Clear polycarbonate  Housing Material  Black nylon  Cord Clamp Material  Natural (white) nylon  Blade Material  Brass  Terminal Clamp Material  .08" (2) steel-nickel plated  Terminal Screw Material  #10-32 Brass (white finish on neutral screw when used) Multi-drive  Ground Screw Material  #10-32 Brass (green finish) Multi-drive  Cord Clamp Screw Material  Steel, zinc plated Multi-drive  Body Holding Screw Material  Steel, zinc plated Multi-drive  Ratings  Molded In or Stamped On  Catalog No  Permanently ink marked on product  Dielectric Voltage Withstand  2,000V minimum  Current Interrupting  Certified for current interrupting at full rated current  Temperature Rise  Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.  Cord Accommodation  Round portable service cords of diameters commensurate with the device rating as defined in UL Standard 62, CSA C22.2 No. 49.  Terminal Accommodation  30A #10 AWG  Terminal Identification  Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)  Flammability  HB or better per UL 94 or CSA 22.2 No. 0.6  Operating Temperatures  Maximum Continuous 75 C Minimum -40 C (w/o impact)  Moisture Resistance  IP20  Listings  FED SPEC UL/CSA  UPC Number  783585039312
