Hy Series Professional Variable Frequency Drive Vfd Inverter 1.5kw 2hp 220v

US $75.00

Los Angeles, California, United States
Jan 29th

Open on mobile:
QR code

Parameters: 1) Input Voltage: 220V(+/-15%) ,We also stock 380V(+/-15%), please contact us for item stock. 2) Output Voltage 110 VAC or 220VAC 3) Input Frequency: 48-63 Hz 4) Output Frequency: 0-400 Hz 5) Input Phase: 1 or 3 phase 6) Output Phase: 3 phase Description: 1)PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability; 2)Easy PLC function can realize 16 legs of speed and inverter control function; 3)RS485 communication port, adopting standard international MODBUS main circuit control; 4)With extremely strong anti-jamming capability 5)Low output ratting torque0.5HZ-150%, low speed running ability; 6)Carrier adjustable by 16KHZ, completely soundless working environment; 7)Broad voltage working area, normal running in 304V-456V; 8)Auto voltage regulation (AVR) technique, for ensuring the inverter load capability; 9)Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes; 10)With perfect error protection and short circuit starting protection capability; Specification: Series HY inverters Control Mode SPWM Input Power 380V class:380V(+/-15%);220V class:220V(+/-15%) 5-Digits Display & Status Indicator Lamp Displaying frequency, current, revolution, voltage, counter, temperature, FOR or REV rotation, and fault, etc. Communication Control RS-485 Working Temperature -10~40 Celsius Degrees Humidity 0-95% Relative Humidity(without dew) Vibration Below 0.5G Frequency Control Range 0.1~2500.0Hz Accuracy Digital: 0.1%(-10~40 Celsius Degrees); Analog: 0.1% (15Celsius Degrees---45Celsius Degrees) Setting Resolution Digital: 0.1Hz; Analog: 0.1% of max. Operating frequency Output Resolution 0.1Hz Operator Setting Method Press directly keys to set. Analog Setting Method External Voltage 0-5V,0-10V,4-20mA,0-20mA. Other Functions Frequency lower limit, starting frequency, stopping frequency, three skip frequencies can be respectively set. General Control Ramp Control Selectable 4-speed steps ramp-up and -down time (0.1-6500s). V/F Curve Set V/F curve at will. Torque Control Torque increase settable by max. 10.0%. The starting torque can reach 150% at 1.0Hz. Multi-Inputs 6 multi-function input terminals for 8speed steps control, program operation, switching of 4-speed Ramp, UP/DOWN function, counter, external emergency stop and other functions. Multi-Outputs 5 multi-output for displaying of running, zero speed, counter, external abnormity, program operation and other information and warnings. Other Functions Auto Voltage Regulation(AVR), Decelerating Stop or Coasting Stop, DC Braking, Auto Reset and Restart, Frequency Track, PLC Program Control, Traverse Control, Drawing Control,Auto Energy Saving, Carrier Adjustable (Up to 20KHz), etc. Protection Functions Overload Protection Electronic relay protection motor drive Drive(for constant torque 150% per min. for the kinds of fan 120% per min.) Fuse Protection When the fuse breaks, the motor will stop. Over-voltage 220V class:DC Voltage >400V 380V class:DC Voltage >800V Under-voltage 220V class:DC Voltage <200V 380V class:DC Voltage <400V Restart After Instant Stop Restart with Frequency Track after Instant Stop Stall Protection Stall protection in ramp operation Output Short Circuit Electrical circuit protection Other Functions Fin over-heat protection, restriction of reverse running, direct start after power on, fault reset, parameter lock PID, one-drive-more, etc. What in Package: 1 x Variable Frequency Drive Inverter 1 x Manual USA SHIPPING ONLY!!! NO RETURNS!!
