Ics Electronics 4823 Ieee488/ieee-488 Bus Interface Card Module/board

US $199.99

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! ICS Electronics 4823 IEEE488/IEEE-488 Bus Interface Card Module/Board Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from ICS Electronics and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit was removed from a working system. It is sold as-is, untested. Link to the Manual: ICS Electronics 4823 Interface Card Manual Description: The 4823 is usd to interface Binary or BCD instruments to the IEEE 488 Bus. The 4823 can be configured to accept data from the bus and convert it to parallel BCD or Binary data for the instrument, or to convert BCD or Binary data from an instrument and format it for the bus. The 4823 is cotnrolled by a program in an on-board EPROM. It can be furnished with a special program to perform any combination of or 2 talk or 1 or 2 listen channels when passing data between the IEEE 488 Bus and an instrument. Specifications: Logic Levels: Talker: High: +2.0 to +5 Vdc @ 20 micro amp Low: -0.5 to +.5 Vdc @ 20 micro amp Listener: High: +2.5 to +5 Vdc @ 200 micro amp Low: 0.0 to .5 Vdc @ 5 milli amp Data I/O: Talker: 0 thru 9 +-.,E space (Can be defined in program code conversion table) Listener: 0 thru 9 :;? (Fixed - can only be changed by a custom program Address Capability: Switch: External (or optional internal) switch allows addresses 0 thru 30 or TALK only LISTEN only. Optional second channel is 1 address above this setting. Indicators: LEDs: PWR ON when card has +5 Vdc and has passed self-test, RDY ON when STATUS A & B lines are TRUE, MTA ON when 4823 is addressed to TALK, MLA ON when 4823 is addressed to LISTEN, Flashing LEDs indicate self-test failure. IEEE 488 Interface: Talker/Listener: SH1, AH1, T5, L3, SR1, PPO, RL1, DC1, DT1, CO, E1 Power Requirements: +5 ±0.25 Vdc, 500 milliamp max. (400 milli amp without leds) Size: DIN 41494 - 100 mm W x 160 mm L x 15 mm H (3.94" x 6.30" x 0.60") Weight: 10 ounces Temperature: 0°C to 70°C free air, -20°C to +85°C storage Connector: 3 x 32 pin DIN - Mounts to DIN 41612 connector. Connector for all I/O to 4823. For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $00.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 12/02/14 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“This unit was removed from a working system. It is sold as-is, untested.”
