Ideal Dc Vdc Amp Amperes Meter Gauge Dial -3 +3 1.625" 59-7382 Military Surplus

US $620

Westerville, Ohio, United States
Jun 6th

Open on mobile:
QR code

FOR SALE IS A BRAND NEW IDEAL PRECISION AMMETER. MODEL 131, 1.625" SQUARE. MILITARY SURPLUS. THE PART NUMBER IS 131 59-7382. THE NSN IS 6625007203661. THE SPECIFICATIONS ARE AS FOLLOWS: AACT Circuit Current FOR Which Designed DC ABHP Overall Length 1.625 inches maximum ABKQ Center TO Center Distance Between Mounting Facilities Parallel TO Length 1.306 inches minimum and 1.318 inches maximum ABKR Center TO Center Distance Between Mounting Facilities Parallel TO Width 1.306 inches minimum and 1.318 inches maximum ABKW Overall Height 1.795 inches minimum and 1.805 inches maximum ABMK Overall Width 1.795 inches minimum and 1.805 inches maximum ABTB Mounting Hole Diameter 0.120 inches minimum and 0.130 inches maximum ABWG Scale Division Quantity 5 single indicator single range AMKD Indicator Type Dial W/pointer AMQY Installation Design Panel ANRL Mounting Arrangement Style Four hole/stud rectangular/square APMM Dial Scale Marking Color Black single indicator single range APPN Accuracy IN Percent -3.0/+3.0 at full scale single indicator single range APST Meter Depth Behind Mounting Flange 1.250 inches maximum APSW Meter Body Diameter Behind Mounting Flange 1.510 inches maximum AQEC Movement Type Moving coil, permanent magnet AQFY Background Color White single indicator single range AXHR Mounting Facility Type AND Quantity 4 unthreaded hole BHMW Measurement Range -50.0/+50.0 microamperes, dc single indicator single range CTQL Movement Suspension Method Jewel pivot base CTTD Circuit Attachment Method AND Quantity 2 solder lug STYL Style Designator Rectangular flush mtg TEST Test Data Document 81349-MIL-10304 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.). IF YOU HAVE ANY QUESTIONS, PLEASE FEEL FREE TO CALL ME 1-614-580-0951. You will not be disappointed. My feedback speaks for itself. If you have any questions please email me and check out the other items I have for sale. If you have problems with your order, PLEASE CONTACT ME BEFORE LEAVING FEEDBACK. Thanks, Mark ATTENTION! – ATTENTION! – NOTICE! – NOTICE! BEFORE LEAVING FEEDBACK PLEASE CONTACT ME. I WANT TO MAKE YOU HAPPY AND FIX THE ISSUE. IF YOU BOUGHT THE WRONG THING, IT IS BROKEN, IF SHIPPING TOOK TOO LONG OR EVEN IF YOU’RE HAVING A BAD DAY. I WANT TO HELP!! I WANT TO KEEP MY FEEDBACK CLEAN.
