IDTP9120 Programmable Triple Channel PMIC Solution Evaluation Board, US $280 – Picture 0
IDTP9120 Programmable Triple Channel PMIC Solution Evaluation Board, US $280 – Picture 0

Idtp9120 Programmable Triple Channel Pmic Solution Evaluation Board

US $280

  • Surprise, Arizona, United States
  • Jun 10th
Open on mobile:
QR code
P9120-EVAL IDTP9120, IDTP9122 Programmable Triple Channel PMIC Solution Evaluation Board The IDTP9120-EVAL is an evaluation board for the IDTP9120 - Programmable Triple Channel PMIC as well as the compatible IDTP9122 - Programmable Dual Channel PMIC. The board provides all necessary connections to evaluate the device features and performance. The integrated load resistor assembly with load switch FET and various test connectors allow for easy transient response testing. The board can be connected to the optional USB-BRIDGEV2-EVAL adapter to program the internal configuration memory of thePMIC via Graphical User Interface (GUI). For that purpose, the board is populated with the “unconfigured” option of the IDTP9120 (IDTP9120-00NBGI). Features Evaluation board including the IDPT9120-00NBGI PMIC Operates from a single supply  3.3 V or 5 V Fully assembled with test points and stand-offs Switch array to set device inputs USB to I2C dongle board interface for GUI PC connectivity Optional software tool to monitor operation and programming On-board load resistors configurable for static and dynamic load operation. Fully assembled 4 layer PCB NO RETURNS UNLESS DAMAGED In Transit by carrier (photos required)
