Indi-square Squareness Gage With Granite Master & Magnetic Parallel Model 8

US $990.00

Rochester, New York, United States
Jan 30th

Open on mobile:
QR code

You are bidding on a Indi-Square Squareness gage, Model 8 - Recently Calibrated. INDI-SQUARE instruments are used by manufacturers and machine tool builders industry wide in inspection departments and tool rooms. Because they are portable, they are easily used on the shop floor for checking in process work at production setups or on large parts themselves. The INDI-SQUARES provide precision squareness and vertical straightness measuring with the exclusive proven anti-friction lifetime sliding mechanism. Model 8 Indi-Squares are simple to use, allowing the user to rapidly check the squareness and straightness of surfaces to .00005 over 9" of travel. INDI-SQUARE measuring instruments are durable. No lubrication or special maintenance is required. If damaged or broken, they may be repaired at the factory and returned with a new "Certificate of Repair and Calibration" and a new full one year warranty. 1.) Hardened , ground and STABILIZED gaging column with two extremely accurate ball spline groves, ground in front and rear. It is held at the bottom in a spring loaded spherical ball seat. The top is held by two highly accurate eccentrics for adjustment. 2.) Completely ANTI-FRICTION, ball recirculating, gaging head. The balls circulating against the spline grooves in the gaging column. The rear ball system is spring loaded, constantly eliminating any play or shake. THIS IS A VERY IMPORTANT FEATURE, GUARANTEEING NEW ACCURACY FOR YEARS OF SERVICE. 3.) Eccentrics for adjusting the gaging column front to back and side to side. One in the side of the unit and one in the rear. They are adjusted by simply turning eccentrics with allen wrench supplied, and tramming indicator up and down granite master - supplied. This is done very quickly. Once calibrated it should not be necessary again, unless surface plate is not accurate. 4.) Adjustable indicator bracket to position indicator. 5.) Indicators: Use your choice, however we recommend the vertical type (easier to read and closer to the head for rigidity) with the universal dovetail clamp. 6.) Knob for raising and lowering head 7.) Hardened, ground and lapped feet. THEY ARE RIGIDLY FIXED TO THE BASE CASTING. Adjustment is made at the top of the unit with no loose connection at the surface area to disturb accuracy. 8.) Front pads for moving instrument sideways. For use in certain fixture applications New Cost -- $3500 Includes the very nice storage/carrying case For more Information see: http://www.indi-square.com/8.htm The INDI-SQUARE COMPANY has been manufacturing precision squareness measuring instruments at a manufacturing location in Rochester, New York since 1960. I will fully guarantee this precision tool - Proudly Made in the USA. We have lots of quality tools available - see my other auctions. Shipping in the Continental US is $19.90 - I have very competitive rates for our always welcomed International bidders . Thanks for looking! If you have any question on this item please call us at 1-800-826-3433 (9 - 5pm Eastern). Pay me securely with your Visa or MasterCard through PayPal! Powered by SixBit's eCommerce Solution

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Type	Squareness Gage
Part Number	Model 8
Manufacturer	Indi-Square
