Instek Psb-2400l2 2 Ch Programmable Dc Power Supply, 80v/40a/800w

US $1359

Melrose, Massachusetts, United States
Jun 16th

Open on mobile:
QR code

Subscribe to Our Newsletter Instek PSB-2400L2 2 Channel, Programmable, Multi-range output DC power supply, 80V/40A/800W Brand: Instek Model Number: PSB-2400L2 Ref No: PSB2400L2 Condition: NEW Data Sheet Product Overview Features Output Volatge Rating: 80V x 2CH Output Current Rating: 40A x 2CH Output Power Rating: 800W Constant Power Output for Multi-Range (V&I) Operation Series and Parallel Operation (2 Units in Series or 4 Units in parallel Maximum) Sequence function edited by PC will be controlled through power supply optional interface Standard Interafce: RS-232C / USB / Analog Control Interface Optional Interface: GPIB Description The Instek PSB-2400L2 2 Channel Programmable, Multi-range output DC power supply, which is a high power density, programmable and multi-range output DC power supply. The Instek PSB-2400L2 has the output voltage of 0~80V, and the output power ranges of 0~400W. The multi-range output functionality facilitates flexible collocations of higher voltage and larger current under the rated power range. Both series and parallel connections can be applied to the Instek PSB 2400L2 to fulfill the requirements of higher power output range.|The Instek PSB2400L2 provides three sets of preset function keys to memorize regularly used settings of voltage, current and power that users can recall rapidly. The sequence function, via RS232C, USB interface or optional GPIB interface, can connect with the computer to produce output power defined by sequence of a series of set voltage and current steps that are defined by the computer. This function is often used to establish a standard test procedure for the verification of the influence on DUTs done by the swiftly changing operating conditions.|The Instek PSB-2400L2 protects over voltage and over current. The power supply output function will be shut down to protect DUTs while the protection mechanism is triggered to function. When conducting battery charging operation, the Hi-W mode of the Instek PSB-2400L2 will prevent reverse current from damaging power supply. The Instek PSB-2400L2 provides analog control and analog monitor interfaces on the rear panel to control Instek PSB-2400L2 output via the external voltage or to externally monitor voltage and current output status of power supply. The Instek PSB-2400L2's panel can be rotated 90 degree angle suitable for vertical or horizontal position to accommodate the ideal space utilization.|Multi-range Output: Compared with the maximum power output of the conventional power supply that is calculated by the maximum output voltage muliples by the maximum output current, the Instek PSB-2400, defying the formula, has a unique characteristic of multirange output (Voltage and current). This distinguishing feature, under the same maximum power output range, can output a higher voltage with a smaller current and vice versa. For instance, for a conventional power supply with a maximum power output of 360W, the maximum voltage and current outputs are likely to be 10V and 36A respectively. Comparatively, Instek PSB-2400L2, with the maximum breaking the limitation of Pmax=Vmax x Imax, broadens voltage and current application ranges, The following diagrams illustrate the voltage and curent comparison between the multi-range output power supply and the conventional power supply.|Series & Parallel Connections: Hence, the Instek PSB-2400L2, with its multi-range output function and the power extension capability of the series and parallel connections, is the high power density and high performance to cost ratio DC power supply, which provides a wider range of power aplications for any limited equipment space. The Instek PSB-2400L2 is an ideal selection for testing DC power supply module, automobile lithium and lithium iron battery and electronic parts.|Preset Function: The Instek PSB-2400L2 provides three sets of parameter preset function keys on the front panel and each parameter preset memory includes output voltage, output current, and output power. Users can speedily recall frequency used settings through operating the front panel preset keys to store everyday settings.|OVP & OCP Functions: When the voltage and current output exceed the preset conditions, the Instek PSB-2400-L2 will shutdown the output function to prevent DUTs from damaging. The OVP and OCP protection level can be set to 10% ~ 110% of the rated voltage or current and the preset condition is 110% of the rated voltage and current.|Tracking Function: The tracking function of the Instek PSB-2400 L2 allows the setting of both channels is changed at the same time. When the value of the one channel is changed, and the other channel will automatically chante its value accordingly if the tracking function is active (On).|Sequence Function: When applying sequence functions, the computer must first edit a series of steps defined by different voltage, current, and duration. These steps are then sent to the Instek PSB-2400L2's memory, in CSV format, via RS-232C, USB interface or GPIB interface (optional) to periodically produce a series of steps defined by a different voltage, current, and duration. The minimum for each sequence is set to one second and the maximum number of step is 100. This function is to test the impact of DUTs done by the rapidly changing power supply. The reliability test of electronics products toward changing power supply is one of the very important verification items.|90 Degree Angle Rotatable Control Panel: Taking working space utilization into consideration, the Instek PSB-2400L2 can be placed vertically or horizontally by its unique design of 90 degree angle rotatable control panel for users' ease-of-use.|Delay Function: The Delay function adds a rise and fall delay time to the outpt of channel 2 for a specific amount of time (in seconds) from a reference point (Output of channel 1). The rise delay time refers to the delay time fo turning the output on. The fall delay time refers to the delay time for turning the output off.|External Control & Analog Monitoring Function: The rear panel of the Instek PSB-2400L2 provides 26pin analog control connector and users can control output voltage and current value via external voltage or resistance. Furthermore, the Instek PSB-2400L2 power supply's output on and off or AC input shut down can also be executed through the external control connector. The designated pin of the port can be measured to monitor output voltage and current. The following diagrams illustrate several typical external control application connections. Terms & Conditions Please note estimated delivery time above. Contact us for details or if you have a delivery requirement. We ask for your patience while striving to ensure your shipment arrives quickly and accurately. Domestic Shipping FREE Standard Shipping on items OVER $75 to continental U.S. Add $24 for AK, HI, or PR. PO Boxes/APOs require USPS shipping and may therefore experience longer lead times 6.25% Sales Tax for shipping to MA International Shipping Due to international voltage requirements, please ask us prior to purchasing to confirm your product will operate correctly in your country. Please contact us for shipping rates to any overseas U.S. territories. International customers are responsible for all shipping charges, including any duties or taxes.
