Instek Psb-2800ls Slave/booster Unit For Current Extension Only

US $1,450.00

Melrose, Massachusetts, United States
Jun 9th

Open on mobile:
QR code

Subscribe to Our Newsletter Instek PSB-2800LS Slave/Booster unit for Current Extension Only Brand: Instek Model Number: PSB-2800LS Ref No: PSB2800LS Condition: NEW Data Sheet Product Overview Features Output Volatge Rating: 800V Output Power Rating: 400W Constant Power Output for Multi-Range (V&I) Operation Series and Parallel Operation (2 Units in Series or 4 Units in parallel Maximum) Standard Interafce: RS-232C / USB / Analog Control Interface Description The Instek PSB-2800LS Programmable, Multi-range output DC power supply, which is a high power density, programmable and multi-range output DC power supply. The Instek PSB-2800LS has the output voltage of 0~80V, and the output power ranges of 0~400W. The multi-range output functionality facilitates flexible collocations of higher voltage and larger current under the rated power range. Both series and parallel connections can be applied to the Instek PSB 2800LS to fulfill the requirements of higher power output range.|The Instek PSB2800LS provides three sets of preset function keys to memorize regularly used settings of voltage, current and power that users can recall rapidly. The sequence function, via RS232C, USB interface or optional GPIB interface, can connect with the computer to produce output power defined by sequence of a series of set voltage and current steps that are defined by the computer. This function is often used to establish a standard test procedure for the verification of the influence on DUTs done by the swiftly changing operating conditions.|The Instek PSB-2800LS protects over voltage and over current. The power supply output function will be shut down to protect DUTs while the protection mechanism is triggered to function. When conducting battery charging operation, the Hi-W mode of the Instek PSB-2800LS will prevent reverse current from damaging power supply. The Instek PSB-2800LS provides analog control and analog monitor interfaces on the rear panel to control Instek PSB-2800LS output via the external voltage or to externally monitor voltage and current output status of power supply. The Instek PSB-2800LS's panel can be rotated 90 degree angle suitable for vertical or horizontal position to accommodate the ideal space utilization.|Series & Parallel Connections: Hence, the Instek PSB-2800LS, with its multi-range output function and the power extension capability of the series and parallel connections, is the high power density and high performance to cost ratio DC power supply, which provides a wider range of power aplications for any limited equipment space. The Instek PSB-2800LS is an ideal selection for testing DC power supply module, automobile lithium and lithium iron battery and electronic parts.|Preset Function: The Instek PSB-2800LS provides three sets of parameter preset function keys on the front panel and each parameter preset memory includes output voltage, output current, and output power. Users can speedily recall frequency used settings through operating the front panel preset keys to store everyday settings.|OVP & OCP Functions: When the voltage and current output exceed the preset conditions, the Instek PSB-2800LS will shutdown the output function to prevent DUTs from damaging. The OVP and OCP protection level can be set to 10% ~ 110% of the rated voltage or current and the preset condition is 110% of the rated voltage and current.|Sequence Function: When applying sequence functions, the computer must first edit a series of steps defined by different voltage, current, and duration. These steps are then sent to the Instek PSB-2800LS's memory, in CSV format, via RS-232C, USB interface or GPIB interface (optional) to periodically produce a series of steps defined by a different voltage, current, and duration. The minimum for each sequence is set to one second and the maximum number of step is 100. This function is to test the impact of DUTs done by the rapidly changing power supply. The reliability test of electronics products toward changing power supply is one of the very important verification items.|90 Degree Angle Rotatable Control Panel: Taking working space utilization into consideration, the Instek PSB-2800LS can be placed vertically or horizontally by its unique design of 90 degree angle rotatable control panel for users' ease-of-use.|External Control & Analog Monitoring Function: The rear panel of the Instek PSB-2800/LS provides 26pin analog control connector and users can control output voltage and current value via external voltage or resistance. Furthermore, the Instek PSB-2800 LS power supply's output on and off or AC input shut down can also be executed through the external control connector. The designated pin of the port can be measured to monitor output voltage and current. The following diagrams illustrate several typical external control application connections. Terms & Conditions Please note estimated delivery time above. Contact us for details or if you have a delivery requirement. We ask for your patience while striving to ensure your shipment arrives quickly and accurately. Domestic Shipping FREE Standard Shipping on items OVER $75 to continental U.S. Add $24 for AK, HI, or PR. PO Boxes/APOs require USPS shipping and may therefore experience longer lead times 6.25% Sales Tax for shipping to MA International Shipping Due to international voltage requirements, please ask us prior to purchasing to confirm your product will operate correctly in your country. Please contact us for shipping rates to any overseas U.S. territories. International customers are responsible for all shipping charges, including any duties or taxes.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Instek
MPN	PSB-2800LS
