Internet/ethernet 12 Relay Board Jqc-3fc - Snmp, Web, Xml, Adc, Counters, Timers

US $310

Europe, Bulgaria
Jun 9th

Open on mobile:
QR code

Denkovi Assembly Electronics ltd. Internet / Ethernet SNMP WEB Data Acqusition I/O Module General description The next generation Ethernet SNMP and WEB relay I/O module based on DAEnetIP4 with 12 SPDT relays (up to 12A), 8 ADC inputs (0-10V) and 8 digital inputs (0-12V) plus 2 PWM outputs (0-3.3V). With its built in real time clock and individual pulse timer functionfor every relay it is suitable for controling electrical devices and monitor different sensors from the ethernet network, orginze thermoregulators or home automation applications. It can be accessed locally (LAN) or remotely (Internet,WAN) via web browser, computer software or smartphone. We provide various software examples for easy integration in your code - Java, .NET, LabVIEW, PHP. Now with free iOS mobile App! Features: 10/100 Full duplex Ethernet interface (Auto MDIX); 12 SPDT relays - JQC-3FC/T73; 8 x analog inputs with 10 bit resolution (0-10VDC); 8 x digital inputs port (0-12VDC). The inputs are combined with 16 bit cyclic counters as well; 2 x PWM outputs port (0-3.3VDC); Hardware "Pulse" function for the relays; Standart protocols: ARP, IP, ICMP (ping), DHCP, DNS, NTP; SNMPv1 - snmpset, snmpget, snmptrap, snmpbulk, snmpgetnext, snmptable,snmpwalk; SNMPv1 Traps upon analog input, digital input event or boot; HTTP access - via web browser (integrated WEB server for all functions/parameters access with autorization); HTTP/XML commands including support for encrypted requests; Built-in Real Time Clock (RTC) with back-up power supply source for days; Weekly schedule table for up to 30 records - the module it can work without PC connected; The ports for HTTP, SNMP and Traps can be changed; Function "load outputs states from EEPROM on boot"; Each I/O line can be named by user via web browser/snmp; A Relay can be assigned to be controlled by analog and/or digital input according input level/edge; Possibility of connection analog sensors to the analog inputs as LM34DZ, LM35DZ, LM335, MCP9700A; Software examples: .NET, Java, Labview and PHP; Denkovi software: DAE-iModules - FREE iOS mobile app Product user'a manual: download; DAEnetIP4 user's manual: download; Please note this is replacement for the legacy product: Internet/Ethernet 12 Channel Relay Board - I/O, SNMP, Web (however the snmp command are not the same). The auction includes 1 x DAEnetIP4 Ethernet controller - user manual here 1 x DAE-PB/RO12/DI8/AI8 peripherial board - Documentation DRM Software - Denkovi Relay Manager Software. CD is not included in the package but the software is available for download from this link Application examples Control devices depending on analog input value (temperature, hummidity, voltage) Home Automation Irrigation systems applications Controlling electrical appliances remotely Monitoring sensors online Controlling electrical devices depending on sensors values Web based thermo-regulator Application for counting customers in shops Remote Lock/unlock doors Suitable for school and university education Web based thermoregulator application Collecting data from sensors remotely via Internet Control electrical devices remotely Control devices depending on sensors levels Module Overview Technical parameters PCB size (LxW), mm 209.68 x 85.85 PCB weight, g 300 Power supply voltage,VDC 12 ± 2 Maximum current consumption at 12VDC (when all relays are ON), mA 700 Operating temperature range, °C 0 to 70 Relays JQC-3FC/T73 maximum switchable current / voltage 7A / 250VAC, 10A / 125VAC, 12A / 120VAC, 10A / 28VDC Please note the product does not come with power supply adapter that you may need. We offer suitable 12V adapters with plug-in outlet for your country - please check out our store. DAE-iModules iOS App DAE-iModules iOS mobile App We, from Denkovi A E LTD, developed absolutley free iOS App DAE-iModules which allows you to access the I/O lines of the current device and will turn your mobile smartphone in powerful automation tool. Support link: here. The video bellow shows how you can control DAEnetIP4 based device - Internet/Ethernet 12 Channel Relay Board. Any other Denkovi Ethernet Device from this list can be acessed with same success from your iOS device via DAE-iModules. Some useful information about DAE-iModules and DAEnetIP4: Select device DAEnetIP4. Enter the IP, UDP Port and SNMP Community for the device Access via web browser DAEnetIP4 has internal web server for access and configuration of almost all parameters. It can be accessed via any browser supporting javascript. It is tested with Internet Explorer, Firefox, Chrome, Safari. It is tested with the browsers of the Android and iPhone mobile devices and works well. DRM Software DRM Software Denkovi Relay Manager (DRM) is multiplatform software for easy controlling all kinds of Denkovi relay boards (USB,SNMP,TCP/IP) The item is supported by DRM Software (it can be controlled only the relays). DRM Software will hep you to save money for expensive software and time in programming. It allows you to switch ON/OFF your devices at particular date and time, turn ON/OFF the relays with pulses or control them via specific sequence. If you have ordered at least one of our relay boards from this list you may turn your PC in powerful automation tool. Multiplatform software: supported by Windows/Linux (ver. 2.0) Control up to 32 relay boards User-friendly intuitive interface Save/Load file Control mode: single and multiple setting of the relays Single pulse with adjustable delay from the control mode (ver. 2.0) Timer mode: create timer playlist for the relays Weekly mode: each relay may be turned ON/OFF on each day of the week Calendar mode: each relay may be turned ON/OFF on particular date at particular time Pulse mode: each relay may work in pulse mode by setting duration for ON and duration for OFF. Adjustable number of pulses (ver. 2.0) Each relay from each relay board can work independently in some of the five modes Each relay board and each relay can be named by the user Indicator panel Auto load function - the last working file is loaded when DRM is started Auto connect function - when the relay board is disconnected DRM will keep trying to find and when this is done, the relay board will be connected again Auto start function - DRM software starts when the OS starts (for Windows only) Auto set function - DRM will set the relays automatically when the relay board is connected Possibility of DRM to starts when PC boots and continues to work from the last saved point For more information about DRM Software, screen-shots, detailed description and download - here DRM Software image - control mode for DAEnetIP4 Internet / Ethernet Data Acqusition I/O Module Access via LabVIEW We have created labview demo application for DAEnetIP4 and its project source code can be downloaded from this link - denkovi.com/SoftwareExamples/DAEnetIP4/labview/DAEnetIP4.rar. The .exe file is in the directory as well - it can be used ad standalone application. Command line (Net-snmp) Net-snmp is free command line utility for windows which allows you to execute snmp commands from command line, BAT files, BASH scripts or any other sofwtare that can execute external .exe file or commands from command line. The instructions file how to install net-snmp and example commands can be downloaded from here. Useful links General links DAEnetIP4 user's manual - download DAEnetIP4 SNMP 12 Channel I/O Relay Module user's manual - download SNMP definitions file (MIB file) - here Software by Denkovi DAE-iModules - Mobile app for iOS mobile devices, support link here DRM Software support page - here Denkovi Finder - utility for discovery DAEnetIP4 and smartDEN devices in local network - here Third parity software Net-snmp command line tool for windows and C++ library - here iReasoning MIB browser (very useful tool) - here Software Examples JAVA - Example how to set/get the DAEnetIP4 I/O status via SNMPv1 in Java (Netbeans Project). LabVIEW 2011 - Example how to set/get the DAEnetIP4 I/O status via SNMPv1 in Labview 2011. The .exe file is in the directory "Executable". VB.NET - Example how to set/get the DAEnetIP4 I/O status via SNMPv1 in Visual Basic .NET. C#.NET - Example how to set/get the DAEnetIP4 I/O status via SNMPv1 in Visual C# .NET. PHP Demo - Example how to set/get the DAEnetIP4 I/O status via SNMPv1 in PHP. Images Please read before buy

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	JQC-3FC/T73
Relays count	12
MPN	DAE-PB-RO12-JQC-3FC/DI8/AI8+DAEnetIP4
Power supply	12 VDC
Country of Manufacture	Bulgaria
Software	control, timer, week, calendar, schedule, pulse
Type	Relays
Access way	Web, Software, Command line, SNMP, iOS
Protocol	HTTP, SNMP
UPC	NA
