John Crane 4620p 2.0" Seal Assembly Cartridge

US $200

  • Farmington, Michigan, United States
  • Jun 9th
 Features Dual seal arrangement — incorporates an elastomer O-ring as the dynamic secondary sealing member Inboard primary and mating ring reverse balance design allows for ID or OD pressurization, permitting the dual seal to operate as an unpressurized tandem or pressurized double seal Pumping ring is standard — no extra cost No extra inventory to carry Flow-optimized design with integral pumping ring arrangement Tangential piping ports Increased cooling flow and face lubrication, greatly extending seal life Cartridge design with factory-preset and pressure-tested assembly The only dual cartridge design with a centering ring eliminating need for external setting clips Eliminates potential assembly and installation errors Parameters Temperature Limits 400°F/205°C Pressure Limits 300 psi(g)/20.7 bar(g) process pressure Speed Limits 3600 rpm Size Limits 1"/24mm to 2.75"/70mm Sold as is, never been used, in original packaging, no returns.
