Jovy Systems Re-8500 Infrared Bga Rework Station

US $1,599.00

HK, Hong Kong
Jan 31st

Open on mobile:
QR code

Jovy Systems RE-8500 infrared BGA rework station uses the dark medium infrared technology for lead free soldering and desoldering of any PCB component. Features Lead free and lead compatible soldering tool Safe heating for all kinds of components like SMD, BGA, CBGA, CCGA, CSP, QFN, MLF, PGA and all epoxy non-defiled µBGA etc. 50 thermal settings storage Large lower preheater Positioning during rework process performed by means of the laser pointer on PCB Reflectors for facilitating of the focusing on the upper heater heating area Guaranteed even heat distribution Password data protection Vacuum pick-up pen Dynamic PCB holder with movable axis to suit different PCB shapes PC control, WINDOWS XP, VISTA and WINDOWS 7 compatible Applications Complete range of rework applications in medium and large scale service centers Mobile and radio systems devices repairment Cellular phones, PDAs, handhelds, laptops, notebooks & motherboards repairment LAN devices, network nodes and military communication equipment repairment Portable medical equipment repairment Technical Specifications Heating power, W 3600 Maximum components size, mm 120 x 60 Top heater size, mm 60 x 120 Bottom heater size, mm 350 x 280 (two separate heating zones) Top heater distance to PCB, mm 60 Bottom heater distance to PCB, mm 35 Temperature sensor channels 5 × K-type thermocouple (potential free) Voltage 230 V AC Frequency 50/60 Hz Dimensions, mm 480 x 580 x 360 Package Contents Jovy Systems RE-8500 Infrared BGA Rework Station unit (1 pc.) Control box (1 pc.) K-type thermo-couple (2 pcs.) X-Y table (1 pc.) Upper heater reflectors (4 pcs.) USB cable (1 pc.) Operation Manual (1 pc.) CD (1 pc.) Jovy® PC Suite. RE-8500 Driver. Microsoft .NET Framework 3.5 Redistributable Package. Microsoft Visual C++ Runtime Redistributable. Softcopy of the User's Manual. Adobe Acrobat Reader.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Jovy Systems
Type	with PC synchronization, complex
Model	RE-8500
Upper Heater Size	6x12 cm
Country/Region of Manufacture	China
Bottom Heater Size	35x28 cm
Voltage	220
Heater Type	with ceramic emitter
Warranty	12
PCB Holder Presence	yes
