Keithley 238 High Current Source Measure Unit

US $2,400.00

Gurabo, PR, Puerto Rico
Jan 29th

Open on mobile:
QR code

Keithley 238 Current Source Meter DESCRIPTION The Keithley 238 Source Measure Unit is a fully programmable instrument, capable of sourcing and measuring voltage or current simultaneously. The Keithley 238 is four instruments in one: voltage source, current source, voltage measure unit, and current measure unit. Features and specifications of the Keithley 238 High Current Source Measure Unit include: SOURCE MEASURE UNIT: Sources voltage while measuring current, or sources current while measuring voltage. FUNCTION: Can be used as DC source or meter, sweep source, or full source-measure unit. SOURCE-DELAY-MEASURE CYCLE: Default Delay: Fixed delay for instrument settling. User Delay: Additional delay for device under test or system capacitance. MEASURE: Integration Time Fast: 416 Aµs 4-digit resolution Medium: 4 ms 5-digit resolution Line Cycle: 16.67 ms (60 Hz) or 20.00 ms (50 Hz), 5-digit resolution Elapsed Time: Measures and stores time from sweep trigger to measurement complete for each step of sweep. RANGING: Source: Auto-ranging through keypad entry; fixed range selection using rotary dial and SELECT keys (DC function). Fully programmable in SWEEP function. Measure: Auto or fixed range. Fixed range selection made by choice of COMPLIANCE value. FILTER: Takes n measurements, calculates and outputs average (n = 2, 4, 8, 16, or 32, selectable). SUPPRESS: Subtracts displayed measurement from subsequent readings. MENU: DC Measurement Delay, Default Delay On/Off, Local/Remote Sense, 50/60Hz, IEEE Address, Self Tests. * DATA ENTRY: Numeric keypad or detented rotary dial. TRIGGER: Input and Output: Set for any phase of SOURCE-DELAY-MEASURE sequence or trigger output at end of sweep. Origin: Internal, External (including front panel MANUAL TRIGGER button), IEEE-488 bus (TALK, GET, "X"). MEMORY: Stores one full sweep (up to 1000 points) of source, delay, and measure values, elapsed times, and sweep parameters. Lithium battery backup. INTERLOCK: Use with test fixture or external switch. Normally closed; open puts instrument in standby Last calibration 2013. Full functionality. Great condition.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Keithley
Model	238
