Keyence Ls-7001 Laser Controller

US $999.00

Kansas City, Missouri, United States
Jan 30th

Open on mobile:
QR code

The LS-7001 is a high-speed, high-accuracy digital laser micrometer used for the dimensional measurement of objects without coming into contact with the objects. It is such a versatile model that it has a wide range of applications including in-line measurement and offline measurement. Includes LS-S11 AC power supply and LS-3CA extension cable NOTE: Error-0 as shown in picture means there is no laser head attached, it is not a fault in the controller. Keyence LS-7001 Controller Model LS-7001 Type Standard No. of connectable measuring heads 2 (LS-7070/LS-7030/LS-7010 only) Display Measurement display Main display: 7-segment red LED (Character height: 20.3 mm 0.80") Sub-display: 7-segment red LED (Character height: 9.9 mm 0.39") x 3 Minimum display unit 0.01 ?m 0.0004 Mil to 100 ?m 3.94 Mil (7-level selectable) Display range ±99.99999 to ±9999.9 mm (Linked to minimum display unit setting, mm/inches selectable) Measurement position monitor 7-level display with a red LED Tolerance check output display Green LED (GO), Red LED x 2 (HI, LO) Terminal block*1 Alarm output NPN open-collector output (N.C.) 5-level comparator output NPN open-collector output for OUT1 Comparator ready output Program selection input Non-voltage input x 4 inputs Strobe output NPN open-collector output for OUT1 Statistical processing input — Synchronous input Non-voltage input for OUT1 Analog output ±10 V x 2 outputs Reset input Non-voltage input for OUT1 Auto-zero input Connector I/O SUB mode *3 Statistical processing output — Function output Selectable from focus, area check, and difference check, NPN open-collector output x 2 outputs BCD mode *3 BCD output Measurement data output (Sign + 7 digits), OUT1/OUT2 selectable, NPN open-collector output BCD selection output NPN open-collector output BCD selection input Non-voltage input SUB mode *3 5-level comparator output NPN open-collector output for OUT2 Comparator ready output Statistical processing input — SUB mode *3 Strobe output NPN open-collector output for OUT2 RS-232C interface Measurement data output and control I/O, printer (Baud rate can be selected up to 115.200 bps) Video output — Power supply voltage *2 24 VDC ±10% Current consumption *2 0.7 A max. Enclosure rating IP64 (Panel surface only) Ambient temperature 0 to 40°C (32 to 104°F) Weight Approx. 820 g Connector I/O Synchronous input Non-voltage input for OUT2 Reset input Auto-zero input Relative humidity 35 to 85%, No condensation *1 The rating of the NPN open-collector inside the terminal block is: 100 mA max. (40 V max.), with a residual voltage of 0.5 V max. The rating of the NPN open-collector inside the connector I/O is: 30 mA max. (30 V max.), with a residual voltage of 0.5 V max. The rating of non-voltage input is: ON voltage of 1 V max., OFF current of 0.6 mA max. *2 AC power supply can be used when the LS-S11 (AC power supply stand) is connected. *3 Either SUB mode or BCD mode can be selected. Keyence LS-S11 AC power supply stand Model LS-S11 Applicable controller LS-7001/LS-7601 Power supply voltage 100 to 240 VAC ±10%, 50/60 Hz Current consumption 110 VA max. Ambient temperature 0 to 40°C (32 to 104°F) Relative humidity 35 to 85%, No condensation Weight Approx. 1.7 kg Keyence LS-C3A 3 meter extension cable Model LS-C3A Model name Head-Controller Cable 3-m Outline Cable between the controller and measuring head Applicable product LS-7000 series Number included 1 Length 3m End of cable 1 Straight

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Manufacturer	Keyence
Model	LS-7001
