Keyence Sv-040p1 Servo Amplifier, New In Box, Msrp $1900, Priced To Sell!

US $1,249.99

Cypress, California, United States
Jan 29th

Open on mobile:
QR code

Keyence SV-040P1 Servo Amplifier, NEW IN BOX, MSRP $1900, Priced to Sell! Single-phase 100 to 115 VAC (for 400 W) Model SV-040P1 General specifications Item Specifications Type For 100 V Input power supply Voltage/frequency Main circuit Single-phase 100 to 115 VAC, 50/60 Hz Control circuit Capacity 400W Input power supply Allowable voltage fluctuation Main circuit/control circuit AC85 to 127V Allowable frequency fluctuation ±5% or less Allowable instantaneous outage time Main circuit Full-stop (100% down): 0.5 cycles, half-stop (50% down): 1 cycle Control circuit approx 65ms Overvoltage category III Control method 3-phase full-wave rectification, IGBT, PWM control, sine wave current drive method Feedback 20-bit serial encoder (incremental, absolute) communication Operating environment Operating ambient temperature 0 to +55°C (no freezing) Ambient storage temperature -20 to +70°C (no freezing) Ambient operating/storage humidity 90%RH or less(no condensation) Vibration resistance 4.9 m/s2 (conforms to JIS C 60068-2-6) Shock resistance 19.6 m/s2 (conforms to JIS C 60068-2-27) Operating atmosphere (enclosure rating/pollution degree) Pollution degree: 2 (within a control panel that has a rating of IP54 or higher), however, · No corrosive or flammable gas present · A location that is not subject to water, oil, or drugs · No dust present Altitude 1,000 m or less above sea level Approved standards UL/CSA standards UL508C, CSA C22.2 number 14 CE marking Low-voltage directive EN50178 EMI EN55011 Class A, EN61800-3 EMS EN61800-3, EN61000-6-2 North American EMI standards FCC Part 15 B, ICES-003, Class A Structure Type Base mounting attachment Protection Open, forced Lowest insulation resistance value 1 M? or more, tested with a 500 VDC megger Insulation withstand voltage 1,500 VAC or more (between the primary side and the earth terminal), 1,800 VAC or more (between the primary side and the secondary side) Weight approx 1.5kg Power supply/current capacity and power loss Maximum applicable motor capacity (W) Single-phase 100 VAC 400 Power capacity (VA) per amplifier 1400 Output current (Arms) Continuous Single-phase 100 VAC 2.8 Maximum 9.3 Main circuit power loss (W) Single-phase 100 VAC 25.6 Control circuit power loss (W) 17 Total power loss (W) 42.6 Input rated current Main circuit (Arms) Single-phase 100 VAC 10 Three-phase 200 VAC 3 Single-phase 200 VAC 5 Control circuit (Arms) Single-phase 100 VAC 0.38 Rush current*1 Main circuit (A) 16.5 Three-phase 200 VAC 33 Single-phase 200 VAC Control circuit (A) Single-phase 100 VAC 35 Performance specifications Performance Speed control range 1 to 5,000 (under the condition that the load torque is less than or equal to the rated torque) Speed fluctuation rate During load fluctuation ±0.01% or less with a load fluctuation between 0 and 100% (at the rated rotation speed) When the voltage of the main circuit fluctuates 0% at the rated voltage ± 10% (at the rated rotation speed)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Keyence
Model	SV-040P1
