KomShine KQL-30 Optical Fiber Test Kit plus QX30 OTDR and 500M SM OTDR Cable Box Description KomShine KQL-30 Optical Fiber Test Tool Kit ,QX30 OTDR 500M OTDR Launch Cable Box/OTDR Fiber Rings Standard Package : 1x KomShine Black Fashion Carrying Bag 1x Komshine 500M Fiber Optic OTDR Launch Cable Box 1x Komshine QX30 OTDR KomShine QX30 Singlemode SM 1550nm 30dB Fiber Optic OTDR * Color Display with Touch Screen * * Ships in 24 Hours via Fedex express * * Come with FC+SC+LC Adaptors * * English Languages * * Test Results Analysis softeware * Features: Applicable fiber: SM <8m extra-short event dead zon Wavelength: 1550nm Up to 30 dB High Dynamic Range Distance Range: 4,8,16,32,64,128,256km Pulse with: 10,30,80,160,320,640,1280,5120,1024ns 3.5 inch TFT-LCD (touch screen) USB interfaces, supporting USB stick and printer and direct cable download to PC via ActiveSync Memory capacity >800 traces Built-in lithium battery with high capacity for over 8 hours of operating life Display: Color LCD One year Warran Specifications: Model = QX30 Wavelength(nm) = 1550 Dynamic range(dB) = 30 Pulse width (ns) = 5,20,40,80,160,320,640,1280,2560,5120,10240,20480 Display 3.5 inch TFT LCD touch screen Event blind zone (m) = 8 Attenuation blind zone (m) = 10 Linearity (dB/dB) = ±0.05 dB/ dB Loss threshold (dB) = 0.05 Loss resolution ratio (dB) = 0.01 Sampling resolution ratio (m) = 0.125 to 8 Sampling point = 32k Distance uncertainty (m) = ±(1 m + 5×10-5× distance + sampling interval) Distance scope (km) = 0.3 to180 Memory capacity of trace = SD Card (4G), > 10000 pieces Duration of measurement = Defined by user; 5sec, 10sec, 15sec, 30sec, 1min, 2min, and 3min are selectable Optical interface = FC/UPC+SC/UPC+LC/UPC Data interface = USB interface, SD card interface Visual Fault Locator = Available Power supply = Lithium battery; continuing working duration ≥ 8 hours Warranty period = 12 months Komshine OLC-SM-500 Fiber Optic OTDR Launch Cable Box/Fiber Rings /OTDR Dead Zone Eliminator with Length of 500 Meters * Connector Type: FC/SC/ST/LC(UPC/APC)-FC/SC/ST/LC(UPC/APC) * * The Carrying Case is Made by USA PELICAN: Watertight*, crushproof, and dustproof* * Rubber liner for extra protection doubles as o-ring seal* * Automatic Pressure Equalization Valve - balances interior pressure, keeps water out* * Stainless steel hardware* *Case is able to be submerged under 1 meter of water for up to 30 minutes in accordancewith IP67 testing parameters * Designed to aid in the testing of fiber optic cable when using an OTDR. The OTDR Launch Fiber box is used with Optical Time Domain Reflectometers (OTDR's) to help minimize the effects of the OTDR's launch pulse on measurement uncertainty. Available in many different configurations and fiber lengths. Features: www.komshine.com - Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration - Compound Latch for positive seal and easy opening with locking feature. - Nonmetal construction will not dent, corrode, or conduce electricity - Water and dust prove allowing the unit to be taken into almost any environment - Case can house up to 2,000 meters of fiber - Auto Purge Valve for changes in altitude and temperature Specifications: Length x Width x Height 9.37" x 5.56" x 2.62" Material SR Polypropylene Color Yellow/Blue Weight 0.75 kg (without fiber) Operating temperature -40° to +55°C Typical Loss < 1dB @ 1310nm for 1000 meters Ordering Information: LB-[A]-[B]-[C]-[D] A = Input connector B = Output connector C = Fiber D = Length (km) FC FC S – Single mode fiber ST ST M6 – Multi mode fiber (62.5/125) SC SC M5 – Multi mode fiber (50/125) FCA – FC/APC FCA – FC/APC SCA – SC/APC SCA – SC/APC LC LC MU MU Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. Non-Paying bidders will be reported. Shipping Items will be shipped within 1~2 days upon the receipt of payment. * Please verify your address when checkout from PAYPAL. We will ship item to your PAYPAL address. If other address, please advise us by EBAY or E-mail.* The estimated delivery time is about: (Except Saturday and Sunday) 7~15 workings days to USA/AU/UK/Asian countries by ePacket. 15~25 workings days to Western European countries by Singapore Post Air Mail. 20~30 workings days to most other countries. For some countries, delivery may take more times such as Italy, Russia and Brazil. Delivery maybe delayed due to public holiday. If you don't get your item in 60days, please do not hesitate to contact us via ebay message.Our customer support will check the status for you. Buyer is responsible for the custom duty and local import taxes. Warranty 12 months Manufacturer's Warranty . We guarantee 100% customer satisfaction. If your item is not as described or faulty when you receive it we will replace it for you with no additional charge. Return It is buyer's responsibility to contact us within 30 calendar days of receiving a defective product. Otherwise, no replacement or refund will be made. All items MUST be returned in their original condition. Buyer is responsible for shipping and proof of delivery on all returns. Contact us If you have any questions on anything from details about the product, to policies and procedures that we have in place please let us know! We are here to take care of anything you may want to know. The best ways to contact us are: Via eBay's messaging system Via the live chat system on our website Give us a call
