L/c Inductance Capacitance Lc Meter High Precision For Dip Smd + Free 2 Clips

US $16.99

hong kong, Hong Kong
Apr 30th

Open on mobile:
QR code

L/C Inductance Capacitance LC Meter High Precision For DIP SMD + Free 2 Clips Description: 1. This Meter has three buttons: L / C (inductance, capacitance), L / F (disconnect frequency generator when test inductance, press this button when test Capacitance), Zero (calibration) 2. Before testing , you need to switch to the ( L / C ) button, then calibration ( Zero ) ,the last , measure components . The display shows the components current parameter values . More introduction, please click the following: Demo video or Demo video (same video, but different site) Features: Supply supply: DC +5v ,mini USB interface Measurement accuracy: 2-5‰ Stepping: 0.04pF/0.04uH Capacitance measuring range: 5pF-2uF (Can't test the polarity capacitors, such as electrolytic , tantalum capacitors ) Inductance measuring range: 0.05uH-100H , 100H greater than for reference only. (Inductance stalls actual test voltage is also possible as if the biggest is 9999H, no conditions to the maximum test unit) Effective display digits: 4 digits LCD display mode: 1602. Simple instructions: 1. Test capacitors, three keys are the up state, then the first row to display CX = a number, and then test again zero, remember capacitance cleared without shorting the test side. 2. Test inductance, former two buttons to press, this time the first line to be displayed LX = a number, and then shortingthe test side, then after zeroing use 3. In the test side vacant when reading will be jumping, this does not affect test accuracy and results. Latest video use: http://www.tudou.com/programs/view/8bdjam3ajVM/?phd=99 Capacitance Test Method: After the power is turned on, press the L / C button to make the screen display Cx = Then press the Zero, the screen will display a value that is the value of the calibration capacitor, then release Zero, table displays Cx = 00.00pF, or close to the zero value. Then you need to test the capacitor connected, will show a very precisedegree the capacitance value. Inductance Test Method: Power is turned on, press the L / C button to make the screen display Lx = Then press L / F, so that the screen display 000000Hz, then need to short-circuit test interface, and then press the Zerobutton, the screen will show close to or equal to zero 00.00uH. Zero then release the button. Access the measured inductance, the screen displays the measured inductance is very accurate inductance value. Package list: 1 x High precision L/C meter 1 x SMD clip 1 x DIP clip
