L2750 Dual High Power Low Drop Operational Amplifier (opamp) Eu Seller

US $5.00

Landschau, Czech Republic
Jan 29th

Open on mobile:
QR code

This listing is for 1 piece of L2750 almost Rail-to-Rail Output (AB power output stage) 4-18V Single supply voltage high power operational amplifier in MULTIWATT11 package See the datasheet here OVERVIEW The L2750 is a new technology class AB dual power operational amplifier assembled in Multiwatt 11 package. Thanks to the fully complementary PNP/NPN output configuration the L2750 can deliver a rail-torail output voltage swing even at the highest current. Additional feature is the very low current StandBy function. The high application flexibility of the L2750 makes the device suitable for either motor driving/control and audio applications purposes. FEATURES •HIGH OUTPUT CURRENT •VERY LOW SATURATION VOLTAGE •LOW VOLTAGE OPERATION •LOW INPUT OFFSET VOLTAGE •GND COMPATIBLE INPUTS •STAND-BY FUNCTION (LOW CONSUMPTION) •HIGH APPLICATION FLEXIBILITY PROTECTIONS: •VERY INDUCTIVE LOADS •OVERRATING CHIP TEMPERATURE •LOAD DUMP VOLTAGE •FORTUITOUS OPEN GROUND •ESD APPLICATION SUGGESTION: The high flexibility makes the L2750 suitable for a wide range of applications. * Motor Controller The device can be utilized as a motor controller. Datasheet describes a bidirectional DC motor control suitable for logic driving. In these kinds of application it is possible to take advantage of the high current capability of the L2750 for driving several types of low impedance motors in a broad range of applications. Moreover the low drop allows high start up currents even at lowest supply voltage. * Audio Applications Another typical utilization of the L2750 concerns the audio field, as follows: 1) DRIVER FOR BOOSTER : The remarkably low distortion and noise makes the device proper to be used as high quality driver for main amplifiers (i.e. car radio boosters). An example is shown in the datasheet (see also the relevant characteristics). 2) CAR RADIO BOOSTER WITH DIFFERENTIAL INPUT : Datasheet Fig. 10 shows an example of car radio booster, with a gain of 30 dB, that is specially recommended for active loudspeakers. Among its main feature is the differentialinput and subsequent high noise suppression. The typical output power delivered into a 4? load is 24W (VS = 14.4V; d =10%), as shown by the characteristics enclosed. Buy more and pay only $ 0,5 shipping for additional items. Contact us for more info and/or large quantity price quote. Looking forward to your orders and questions

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ST Micro
Country of Manufacture	Singapore
Model	L2750
