Lc100-a Digital Lcd High Precision Inductance Capacitance L/c Meter Tester

US $560

ShenZhen, China
Nov 13th

Open on mobile:
QR code

LC100-A Digital LCD High Precision Inductance Capacitance L/C Meter Tester +Free Shipping with Tracking Number Product Description Description: Type: Capacitance Meter Model: LC100-A Size: 80x50x3mm Features: 1.Based on the L/C resonance principle 2.High speed microcontroller’s precision computation 3.Measuring range below 1uH and 1pF 4.Especially qualify in microwave manufacture and measuring switching 5.power supply transformer, filter inductance and so on. LC100-Ahas four measuring range position: 1. C range ........Capacitance (0.01pF-10uF) 2. L range ........Inductance (0.001uH-100mH) 3. Hi.L range ......Big inductance (0.001mH-100H) 4. Hi.C range ......Big capacitance range (1uF-100mF) Technique data: Capacitance Test: Capacitance Accuracy: 0.01pF-1pF: 5% 1pF-1uF:1% 1uF-10uF: 5% Min Capacitance Resolution:0.01pF(C Files) Inductance Test: Inductance Accuracy: 0.001uH-1uH: 5% 1uH-100mH: 1% Min Inductance Resolution: 0.001uH (LFiles ) Big Inductance Test: Big Inductance Accuracy: 100mH-1H: 1% 1H-100H: 5% Min Resolution of Big Inductance: 0.001mH (HLFiles) Big Capacitance Test: Big Capacitance Accuracy: 1uF-100mF: 5% Min Resolution of Big Capacitance: 0.01uF (HC Files) Frequency: LFiles/C Files: Abt. 500kHz HLFiles: Abt. 500Hz Other features: Measuring mode: LC Resonance Display mode: 1602 LCD Display digit: 4 Interface: Mini USB & Φ 5.5DC Socket Supply Voltage: 5V Function of five buttons: Red: Reset Write: Big Capacitance Hi.C Choice (With self-locking) Blue: Big Inductance Hi.L Choice (with self-locking) Yellow: L/C(with self-locking) Black: Function button Direction for use: 1.Switch on the L/C Meter 2.Chose the corresponding files, inductance: Lx, capacitance: Cx, big inductance: Hi.L, big capacitance: Hi.C. Display as follows (testing terminal open loop): Inductance: Measure Lx over range Capacitance: Measure Cx 0.00pF Big inductance: Measure Hi.L over range Big inductance: Measure Hi.L over range Display as follows( testing terminal short circuit): Big inductance: Measure Hi.L 0.000mH Inductance: Measure Lx 0.000uH Capacitance: Measure Cx over range 3.When testing terminal open loop the measured value of capacitance is not “0”, or witch of the inductance is not “0” as the testing terminal short circuit, you can reset to “0” by ways of capacitance model and inductance model, as follows: (a) Capacitance model: Press red button as testing terminal open loop, it displays “CALCULATING…”, keep pressing for one second, when “CALCULATING…OK” displayed,release the red button,resetting to “0” is finished, and “0.00pF” is displayed,then capacitances can be measured. (b) Inductance model: Press red button as testing terminal shirt circuit, it displays “0.000uH” or “0.000mH”, and then inductances can be measured. 4.Please press black function button as results displayed, and corresponding frequency will be displayed. Note: 1. Please reset to “0” before testing a capacitance or an inductance, or errors may be appeared. Even if “0” displayed before measuring, resetting to “0” is needed. 2.At the time of resetting to “0”, when“CALCULATING…OK” appeared, please keep pressing for 2 to 3 seconds, and the parameter written to “<DATASAVED>” will be prompted, then release. 3.Resetting to “0” is forbidden as components are being measured. If you do it, please shut down immediately and restart, then reset to “0”. 4.The time of measuring a big capacitance (above 10mF) may be more than one second, and it needs seven to eight seconds to get the measured value of the capacitance (100mF). 5.Forbid to measure a capacitance which is not discharged, otherwise it may damage the mainframe. Package Included: 1X LC100-AL/C Meter 1X SMD Test Clip 1X Mini USB Cable 1X User Manual Payment Method We accept only Paypal for both domestic and international. We will ship to the shown address on you PAYPAL Payment notice,Please confirm your shipping address in the PayPal Account. If buyer want to delay the payment because of financial problem, please contact me by the ebay message within 3 days. Shipping Detail Ship by Post Air-mail within 1-2 working days after full payment is received. The shipment usually takes 15-45 business days to Worldwide. We also provide international Expressed delivery such as EMS, DHL and UPS,extra shipping fees is needed. The shipping time may vary, depends on receiver's location. Feedback Policy We will leave positive feedback to buyer as soon as buyer pays for the item. Leaving Negative feedback or Netural Feedback is never a good way to resolve problem .We hightly appreciate that you can contact with us before you leaving Negative feedback or Neutral feedback .We will offer help to resolve your problems as fast as possible. Customer Service Work Time If you have any questions,Please contact with us via eBay message or our customer service e-mail . please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 09:00 - 20:00 and Saturdays 09:00 – 18:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) On Jul-14-16 at 01:06:51 PDT, seller added the following information:
