LCD Digital Capacitor ESR Tester Internal Resistance Meter Test In Circuit +Clip, US $37.99 – Picture 0

LCD Digital Capacitor ESR Tester Internal Resistance Meter Test In Circuit +Clip, US $37.99 – Picture 1

Lcd Digital Capacitor Esr Tester Internal Resistance Meter Test In Circuit +clip

US $37.99

??, ???, China
Jun 9th

Open on mobile:
QR code

Description: There are some conditions which will cause the electrolyte's resistance (ESR) to increase. This can eventually reach a point where it causes problem with the circuit. The ESR meter can be used to test electrolyte's electrical resistance without removing from the circuit, greatly improved working efficiency. It must be a pretty helper that you need. Features: Meter Shell Size: 130x65x20 (mm) Accuracy: 1% ±2 digit Range: 0.01 - 30 ? Frequency: 100 KHz Test signal: Square pulse Protection: 400V voltage Power consumption: <80mw (low voltage warning) Method of Operation: 1. Long press power key: On/Off the ESR meter 2. Please Connect the test leads to the both ends of capacitor. If the measured resistance's value is much larger than normal value(for example: 10 times larger), it means that the capacitor is ageing, need to be replaced; if the measured resistance's value is much smaller than normal value, it means that there may be electric leakage. 3. Short press the power key: On/Off backlight 4. The first line displays the current ESR value and the second line displays the current battery's voltage. Precautions for Operation: 1. Cut power of the circuit board before measurement. 2. There is the voltage protection of 400V, but for the meter and personal safety issues, please discharge the capacitor. 3. If the value shows on the ESR Meter much larger and can not be zeroed, please check if the two groups of wires and clips are well connected. 4. If you previously use the tweezer and now use the rear socket, you should set to zero, and vice versa. If the displayed value is sharply fluctuating when using the tweezer, please clean or slightly sharpen the tweezer tip in order to improve this situation. 5. In order to get better display effects, you can tear up the screen protector film. Method of adjustment: 1. Set to Zero: Short-circuit tweezer (if use socket, put the short-circuit ring plug into the socket), press the short-circuit function key and the meter displays "offset", that means to automatically return to zero. After that, the ESR Meter will display the offset value for about 2 seconds. 2. Magnification adjusting: Connect two test leads to 15 ohm resistor (Accuracy 1% at least), press twice the function key and the ESR Meter displays "Gain...", that means magnification calibration is in progress. After the calibration, it shows the current measured value. 3. If the offset value is much larger(for example, >0.5 ohm), please repeat twice the above steps to get better effects. This ESR meter can be used to test electrolytic capacitors without removal from the circuit. Microprocessor Controlled and probe resistance set to zero correction, Automatic gain correction. Battery: 2 x AA (2x1.5V) Not include Dimensions: 135x70x25 (mm) Package: In-Circuit ESR Meter and test clip Shipping Item will be shipped out within 2 business days after receipt of your payment, we ship the item through hongkong Air mail or China Post. We Ship to Worldwide, but Italy, Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Payment We ONLY accept payment by Paypal. All payments must be received within 7 working days after auction has ended. Non-paying bidders will be reported to ebay. Feedback If you have any questions or comments about our products or policies, please contact us by emails with your purchased item number. You also can contact us by leaving us an eBay message,we will be responded within 24hours. Customer satisfactory is most important to us. If you have a problem or question regarding your transaction please contact us before leaving any type of feedback. Negative feedback does not solve anything. We are always willing to work things out, thank you!
