Lcd Universal Power Module Switch Power Supply Board 12-18v 300v For Tv Display

US $84

shenzhen, China
Nov 10th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Galler Power Modules Sensors Module Function Modules Development boards Wireless Modules DIY LED Boards LCD Modules Description Universal Power Module Switch Tube For LCD TV Maintenance Pin Definition: 1.1-Pin Yellow Wire:DRAIN,power control port;connect with MOS power tube D pole (usually is power switch tube middle pin) 2.2-Pin Black Or Pink Wire:GND,module ground wire 300V;connect with capacitor negative 3.3-Pin Red Wire:VCC,module power supply port;connect with feedback winding port after rectification capacitor's positive and continuous power supply;voltage range is 12-18V 4.4-Pin White Wire:FB,stabilivolt feedback,connect with optocoupler 4 pin;please make sure that optocoupler 3 pin connect with hot ground;if not hot ground please connect optocoupler short circuit with hot ground,and disconnect 4 pin external circuit at the same time 2.5-Pin Green Wire:start pin,connect with 300V capacitor positive Using Method: 1.Remove original power chip (usually 8-pin) and switch tube (mos tube) 2.Check 300V capacitor 3.Check if load port is short circuit,ad board,inverter board etc 4.Connect module corresponding circuit and check if there is false connection 5.Install it in origial heat sink position,pay attention to insulation,no short circuit 6.Power on,test whether voltage is output or not;please check out the reason if there is no output Shipping Payment Return Gurantee About us 1. Items are only shipped after PAYMENT confirmed. 2. Please check out your Paypal ADDRESS carefully when processing order. 3. Please CONTACT us ASAP if you haven't received the package in 35 days. 4. If you don't receive the parcel in 45 days, please allow us 3-5 working days for checking undelivered parcels before we issue you refund. 1. We only accept Paypal payment if you buy on ebay. 2. Please make sure you notice the entire desciption and agree to the transaction before buying. 1. If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in 30 days and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2. Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3. Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. 1.We Can promise to offer you the refund or replacement if you can not get packages on the normal delivery time. 2.If there is any problems with the item when you get it, please send us the ebay message for solution; Or you can return the item to us in 30 days. In our ebay shop, we mainly sell electronics, outdoor finishing accessoires, and all Funny Sorts. We can als offer wholesale service. inkfrog terapeak inkFrog Analytics On Nov-10-16 at 09:49:04 PST, seller added the following information:
