Lcd1602 Blue Backlight 5v Lcd Module Display White Character 1602a Hot Sale

US $4.20

China, China
Mar 10th

Open on mobile:
QR code

Module Description Specifications Blue-Back white word, 0.036KG Standard 16X2 character LCD module (backlight / blue) 1602 with standard 16 pin connector, including: Pin 1: VSS is in power Pin 2: VDD 5V positive power supply connection Pin 3: V0 LCD contrast adjustment for the client, then the contrast is the weakest power, ground power the highest contrast, the contrast is too high will have a "ghosting", when used with a 10K potentiometer to adjust contrast Pin 4: RS for the register selection, the selection of data register high, low, select the instruction register. Pin 5: R / W to read and write signal lines, when high read, low write. When the RS and RW can be written together for the low level command or display the address, when RS is high, low RW can be read busy signal, when RS is low for the high RW can write data. Pin 6: E side to side to make, when E Duanyou high jump into a low, the LCD module execute the command. Pin 7 to 14: D0 ~ D7 for the 8-bit bidirectional data line. Pin 15 feet: Backlight positive supply Pin 16 feet: Backlight negative supply Payment 1.We accept Paypal only. 2.Please confirm your ebay shipping address is exact after payment. 3.If your purchased is more than $50.00,please offer your phone number with shipping address. Delivery details 1.All item will be shipped by Airmail post within 1 business days. It takes approximately 15-25 days (USA ,CA,AU,UK,DE).other country 15-35 days. 2.Express by EMS ,it must add 25 USD shipping fee, it takes 5-10 workdays for delivery.If you need other Epxress(DHL,Fedex.UPS etc.),please contact us to talk about shipping fee. 3.Once you purchase, please DONOT leave negative, neutral feedback or open any case if you have not received item in 30 days, because we have mentioned the shipping time repeatedly. Contact us ???? 2 1.We offer retail and wholesale services. We can provide products in accordance with your requirements. If you have any questions or something to consult, please send us ebay message. 2.All messages will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your message and we will reply to you as soon as possible. 3.Our aim is to provide Top Level Customer Service, Business hours are 9am to 6pm Beijing time (+8 GMT), Monday to Friday. Engineered for professional eBay sellers!
