Lcr Handheld L/ C Meter Inductance Capacitance Digital Bridge Meter

US $42.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

LCR Handheld L/ C Meter Inductance Capacitance Digital Bridge Meter LCR Handheld L/ C Meter Induct Features: High speed microcontroller’s precision computation Measuring range below 1uH and 1pF Intellectually Shutdown in 5 minutes Especially qualify in microwave manufacture and measuring switching power supply transformer, filter inductance and so on. Meter has four measuring range positions: 1. C range ........Capacitance (0.01pF-10uF) 2. L range ........Inductance (0.001uH-100mH) 3. Hi.L range ......Big inductance (0.001mH-100H) 4. Hi.C range ......Big capacitance (1uF-100mF) All range position are automatic measuring ranges, it is easy to operate. Specification is as follows: 1. Technique data: Item Parameter Capacitance Accuracy 0.01pF-1pF 5% 1pF-1uF 1% 1uF-10uF 5% Min Capacitance Resolution(C Range) 0.01pF Inductance Accuracy 0.001uH-1uH 5% 1uH-100mH 1% Min Inductance Resolution(L Range) 0.001uH Big Inductance Accuracy 100mH-1H 1% 1H-100H 5% Min Resolution of Big Inductance 0.001mH (Hi.L Range) Big Capacitance Accuracy 1uF-100mF 5% Min Resolution of Big Capacitance(Hi.C Range) 0.01uF Frequency L Range?C Range Abt. 500kHz Hi.L Range Abt. 500Hz Display mode 1602 LCD Display digit 4 Power supply interface Mini USB Or Φ5.5DC Socket Or 4 of AA Batteries Supply Voltage 5V Function of five buttons: Red: Reset Blue: Big Capacitance Hi.C Choice (With self-locking) Blue: Big Inductance Hi.L Choice (with self-locking) Blue: L/C Choice (with self-locking) Blue: Function button Details as follows (Press “1”, Release “0”, “X” random) Hi.C Hi.L L/C Corresponding function 0 0 0 Small Capacitance(C) 0 0 1 Small Inductance(L) 0 1 1 Big Inductance (Hi.L) 0 1 0 Error,please modify 1 X X Big Capacitance (Hi.C) 2. Direction for use: (1). Switch on the L/C Meter (2).Chose the corresponding range, inductance: Lx, capacitance: Cx, big inductance: Hi.L, big capacitance: Hi.C. Display as follows (testing lead open loop) : Inductance:MEASURE Lx OVER RANGE Capacitance:MEASURE Cx 0.00pF Big inductance:MEASURE Hi.L OVER RANGE Big capacitance:MEASURE Hi.C 0.00uF Display as follows (testing lead short circuit): Big inductance:MEASURE Hi.L 0.000mH Inductance:MEASURE Lx 0.000uH Capacitance:MEASURE Cx OVER RANGE (3).When testing lead open loop the measured value of capacitance is not “0”, or witch of the inductance is not “0” as the testing lead short circuit, you can reset to “0” by ways of capacitance model and inductance model, as follows: (a) Capacitance model Press red button as testing lead open loop, it displays “CALCULATING…”, keep pressing for one second, when “CALCULATING…OK” displayed, release the red button, resetting to “0” is finished, and “0.00pF” is displayed, then capacitances can be measured. (b) Inductance model Press red button as testing lead short circuit, it displays “0.000uH” or “0.000mH”, and then inductances can be measured. Package: 1. A LC200A L/C Meter 2. A mini USB Cable 3. English Manua 4. 1 pcs red alligator clip and 1 pcs black alligator clip NOTE: (NO INCLUDE ) SMD Test Clip. Payment 1. We accept PayPal only. 2. Payment must be received within 3 Days from the date of purchase. Delivery details 1. Ship worldwide from China by Hong Kong Post/ China Post. Package handling only takes 1 business days at our warehouse. Please note that items purchased on weekends and & Public holiday are despatched the next working day. About us 1. Buyer should check the package once receiving. If the package damage during the freight, please refuse to sign for the package and it will return to us. Then contact us promptly. 2. We accept exchange/replace item within 30 days when customer receive merchandise. Contact us 1. Please contact us if you have any problem. we will resume within 24 hours. 2. Please leave Positive Feedbacks for us if you are satisfied with our products and service, and we will do the same for you. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	L/C Inductance Capacitance Meter
Inductance Accuracy	uH mH
Capacitance Accuracy	pF uF
Supply Voltage	DC 5V
