Leadshine 2phase Stepper Drive Am882 Dc20-80v 0.1-8.2a 200khz For Nema 17-34 New

US $192.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine 2-phase Classic Analog Stepper Drive AM882 DC20-80V 0.1-8.2A New Introductions: The AM882 is a versatility fully digital stepping drive based on a DSP with advanced control algorithm. The AM882 is the next generation of digital stepping motor controls. It brings a unique level of system smoothness, providing optimum torque and nulls mid-range instability. Motor self-test and parameter auto-setup technology offers optimum responses with different motors and easy-to-use. The driven motors can run with much smaller noise, lower heating, smoother movement than most of the drives in the markets. Its unique features make the AM882 an ideal solution for applications that require low-speed smoothness. The AM882 builds the *sensorless stall detection function to eliminate the cost of feedback device and cabling. Apart from the auto configuration, it has extra 16 selectable built-in auto-configuration parameters which are best match to Leadshine stepping motors. *Note: At present the AM882 only detect motor stall when running speed >300RPM. Features: *Sensorless tall detection, eliminates cost of feedback device and cabling(>300RPM) *Anti-Resonance, provides optimum torque and nulls mid-range instability *Motor auto-identification and parameter auto-configuration technology, offers optimum responses with different motors *Built-in auto-configuration parameters for 16 Leadshine stepping motor *Multi-Stepping allows a low resolution step input to produce a higher microstep output for smooth system performance *Microstep resolutions programmable, from full-step to 102,400 steps/rev *Supply voltage up to +80 VDC, Output current programmable, from 0.1A to 8.2A *Pulse input frequency up to 200 KHz *TTL compatible and optically isolated input *Automatic idle-current reduction and software configured reduction rate *Suitable for 2-phase and 4-phase motorsOver-voltage, over-current, phase-error protections *Support PULSE/DIRECTION and CW/CCW modes *Over-voltage, over-current, phase-error protections Specifications: Parameters AM882 Min Typical Max Unit Output current 0.1 - 8.2 (5.86 RMS) A Supply voltage +20 +68 +80 VDC Logic signal current 7 10 16 mA Pulse input frequency 0 - 200 kHz Isolation resistance 500 - - Mohm Applications: Suitable for a wide range of stepping motors, from NEMA frame size 17 to 34. It can be used in various kinds of machines, such as laser cutters, laser markers, high precision X-Y tables, labeling machines, and so on. Its unique features make the AM882 an ideal solution for applications that require both low-speed smoothness and high speed performances. Other hot items of this Leadshine stepper drives for above applications: AM882 Leadshine 2-phase Classic Analog Stepper Drive AM882 DC20-80V 0.1-8.2A New M415B Leadshine 2-phase Classic Analog Stepper Drive M415B DC18-40V 0.21-1.5A New M542 Leadshine 2-phase Classic Analog Stepper Drive M542 DC20-50V 1.0-4.2A New M550 Leadshine 2-phase Classic Analog Stepper Drive M550 DC20-50V 1.2-5.0A New M752 Leadshine 2-phase Classic Analog Stepper Drive M752 DC20-75V 1.8-5.2A New M760 Leadshine 2-phase Classic Analog Stepper Drive M760 DC20-75V 1.45-6.0A New M860 Leadshine 2-phase Classic Analog Stepper Drive M860 DC24-80V 2.4-7.2A New M880A Leadshine 2-phase Classic Analog Stepper Drive M880A DC24-80V 2.8-7.8A New MA860H Leadshine 2-phase Classic Analog Stepper Drive MA860H DC24-80V 2.4-7.2A New We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	AM882
Model	AM882
Country of Manufacture	China
