Leadshine Brushed Servo Motor Dcm50202ad-1000 24vdc 50w 3500 Rpm 1000-line New

US $218.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine Brushed DC Servo Motor DCM50202AD-1000 24VDC 50W 3500 rpm Differential 1000-Line Encoder Screw Mounted New Introductions: Leadshine DCM50202A is a high quality 54mm DC brush servo motors with a 1,000-line differential-ended encoder. The motors are ideal for cost sensitive applications. Built with high quality materials, it moves very quietly and smoothly with high precision and very little motor heating. It has been widely implemented in many OEM applications. Features: *Reliable industrial quality *High performance, Low cost *Rated voltage:24 VDC, Rated power: 50W *54mm frame size *3500 RPM rated speed / 4600 RPM peak *4000 CPR (1000-line) increamental encoder Specifications: Parameters Symbol Units DCM50202A DCM50205 DCM50207 Continuous Torque (Max) TC N.m 0.15 0.25 0.35 Peak Torque (Stall) TPK N.m 0.76 1.59 2.90 No-load Speed SNL rpm 4600±10% 4000±10% 3600±10% Rated Speed SR rpm 3500 3400 2900 Rotor Inertia JM kg.m2 1.62 x 10-5 3.11 x 10-5 4.73 x 10-5 Winding Temperature ?MAX °C 155 (Max) 155 (Max) 155 (Max) Thermal Impedance RTH °C /watt 9.00 7.3 4.98 Weight (Plus Encoder) WM G 694 1182 1338 Length (Plus Encoder) L1 mm 129±2 161±2 196±2 Rated Voltage E V 24 24 30.3 Rated Current I A 1.79 2.95 3.94 Torque Constant KT N.m/A 48 x 10-3 52 x 10-3 80 x 10-3 Resistance RT ? 2.52 0.8 0.9 No-load Current INL A 0.45 0.5 0.45 Peak Current (Stall) IP A 13.9 21.6 32.6 Encoder Resolution - steps/rev. 500/1000 500/1000 500/1000 Applications: The DCM5xxxx series brushed DC servo motors are widely used in inkjet printers, medical equipment, measuring devices, engraving machines, electronic packing equipment and so on. Particularly suited to the applications requiring minimal vibration, super-low noise, high precision and high speed. Other hot items of this Leadshine Brushed servo motors for above applications: DCM50202A-1000 Leadshine Brushed DC Servo Motor DCM50202A-1000 24VDC 50W 3500 rpm Single-ended Encoder Screw Mounted New DCM50205-1000 Leadshine Brushed DC Servo Motor DCM50205-1000 24VDC 80W 3400 rpm Single-ended Encoder Screw Mounted New DCM50207-1000 Leadshine Brushed DC Servo Motor DCM50207-1000 30.3VDC 120W 2900 rpm Single-ended Encoder Screw Mounted New DCM57202-1000 Leadshine Brushed DC Servo Motor DCM57202-1000 24V 50W 3500 rpm Single-ended Encoder Flange Mounted New DCM57205-1000 Leadshine Brushed DC Servo Motor DCM57205-1000 24VDC 80W 3400 rpm Single-ended Encoder Flange Mounted New DCM57207-1000 Leadshine Brushed DC Servo Motor DCM57207-1000 30.3VDC 120W 2900 rpm Single-ended Encoder Flange Mounted New DCM50202A-500 Leadshine Brushed DC Servo Motor DCM50202A-500 24VDC 50W 3500 rpm Single-ended Encoder Screw Mounted New DCM50205-500 Leadshine Brushed DC Servo Motor DCM50205-500 24VDC 80W 3400 rpm Single-ended Encoder Screw Mounted New DCM50207-500 Leadshine Brushed DC Servo Motor DCM50207-500 30.3VDC 120W 2900 rpm Single-ended Encoder Screw Mounted New DCM57202-500 Leadshine Brushed DC Servo Motor DCM57202-500 24V 50W 3500 rpm Single-ended Encoder Flange Mounted New DCM57205-500 Leadshine Brushed DC Servo Motor DCM57205-500 24VDC 80W 3400 rpm Single-ended Encoder Flange Mounted New DCM57207-500 Leadshine Brushed DC Servo Motor DCM57207-500 30.3VDC 120W 2900 rpm Single-ended Encoder Flange Mounted New DCM50202AD-1000 Leadshine Brushed DC Servo Motor DCM50202AD-1000 24VDC 50W 3500 rpm Differential Encoder Screw Mounted New DCM50205D-1000 Leadshine Brushed DC Servo Motor DCM50205D-1000 24VDC 80W 3400 rpm Differential Encoder Screw Mounted New DCM50207D-1000 Leadshine Brushed DC Servo Motor DCM50207D-1000 30.3VDC 120W 2900 rpm Differential Encoder Screw Mounted New DCM57202D-1000 Leadshine Brushed DC Servo Motor DCM57202D-1000 24V 50W 3500 rpm Differential Encoder Flange Mounted New DCM57205D-1000 Leadshine Brushed DC Servo Motor DCM57205D-1000 24VDC 80W 3400 rpm Differential Encoder Flange Mounted New DCM57207D-1000 Leadshine Brushed DC Servo Motor DCM57207D-1000 30.3VDC 120W 2900 rpm Differential Encoder Flange Mounted New DCM50202AD-500 Leadshine Brushed DC Servo Motor DCM50202AD-500 24VDC 50W 3500 rpm Differential Encoder Screw Mounted New DCM50205D-500 Leadshine Brushed DC Servo Motor DCM50205D-500 24VDC 80W 3400 rpm Differential Encoder Screw Mounted New DCM50207D-500 Leadshine Brushed DC Servo Motor DCM50207D-500 30.3VDC 120W 2900 rpm Differential Encoder Screw Mounted New DCM57202D-500 Leadshine Brushed DC Servo Motor DCM57202D-500 24V 50W 3500 rpm Differential Encoder Flange Mounted New DCM57205D-500 Leadshine Brushed DC Servo Motor DCM57205D-500 24VDC 80W 3400 rpm Differential Encoder Flange Mounted New DCM57207D-500 Leadshine Brushed DC Servo Motor DCM57207D-500 30.3VDC 120W 2900 rpm Differential Encoder Flange Mounted New We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com TradeManager: fasttobuy skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.
