Leviton 8480-i 15 Amp, 125 Volt, 4-in-1 Receptacle, Straight Blade, Industrial

US $180

Morton, Pennsylvania, United States
May 27th

Open on mobile:
QR code

Leviton 8480-I 15 Amp, 125 Volt, 4-In-1 Receptacle, Straight Blade, Industrial Series Extra Heavy Duty Hospital Grade, Grounding, Surge with Indicator Light, Ivory Brand Features Leviton’s Surge Protection Devices can be used individually or as part of a coordinated application strategy, to protect sensitive electronic equipment, in industrial, commercial and residential locations, from the stress and degradation inflicted by voltage transients. Leviton Surge Protection Devices are compliant with UL 1449 Standards. Leviton’s outstanding Surge Protection Devices divert damaging voltage transients, or surges, away from electronic equipment. Transients are diverted away from sensitive micro circuitry, providing protection against catastrophic failure, costly downtime and data disruptions. Item Description 15 Amp, 125 Volt, NEMA 5-15R, 2P, 3W, Industrial Series Extra Heavy Duty Hospital Grade, 4-In-1 Receptacle, Straight Blade, Grounding, Surge w/ Indicator Light, Steel Strap - IVORY Electrical Specifications Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current Amperage: 15 Amp Voltage: 125 Volt Pole: 2 Wire: 3 Grounding: Self-Grounding Dielectric Voltage: Withstands 2000V per UL498 Current Limiting: Full Rated Current Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current Environmental Specifications Flammability: Rated V-2 per UL94 Operating Temperature: -40C to 60C Material Specifications Body Material: Nylon Line Contacts: Phosphor Bronze Terminal Screws: Brass 8-32 Grounding Screw: Steel 8-32 w/ 12AWG Green 8 Inch Pigtail Mounting Screws: Zinc-Plated Steel 8-32 Face Material: Nylon Body Material: Polycarbonate Line Contacts: Brass Triple-Wipe Terminal Screws: Brass-Plated Steel Grounding Screw: Brass-Plated Steel Yoke: Zinc-Plated Steel Clamp Nuts: Zinc-Plated Steel Ground Clips: Brass-Plated Steel Shutter Mechanism: Delrin® Acetal Mechanical Specifications Terminal ID: Brass-Hot, Green-Ground, White-Neutral Terminal Accom.: 14-12 AWG Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral Terminal Accom.: 14-10 AWG Product ID: Ratings are permanently marked on device Torque Range: 14-16 inch pounds Performance Data UL1449 Impulse 6kV/500A L-N:330V MCOV: 150V rms Joules Rating: 720 Nominal Discharge Current Rating:3kA Maximum Surge Current, Per Mode (Per Phase): 27kA (L-N:18kA, L-G:9kA) Noise Rejection: -30dB at 500kHz-30MHz VPR: L-N:500V, L-G:600V, N-G:500V Short Circuit Current Rating: 5kA Diagnostics: Indicator Light Product Features Grounding: Grounding Termination: Side Body Material: Nylon UL1449 Impulse 6kV/500A L-N:330V Color: Ivory NEMA: 5-15R Standards and Certifications NEMA: WD-1 WD-6 UL498HG: File E13399 UL Fed Spec WC-596: File E13399 NEMA: WD-6 ANSI: C-73 Agency Certifications: UL 498, UL 1449 3rd Edition Listed and CSA C22.2 Certified Type 3 NOM: 057 Warranty Product Warranty: 10-Year Limited Electrical Specifications Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current Amperage: 15 Amp Voltage: 125 Volt Pole: 2 Wire: 3 Grounding: Self-Grounding Dielectric Voltage: Withstands 2000V per UL498 Current Limiting: Full Rated Current Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current Environmental Specifications Flammability: Rated V-2 per UL94 Operating Temperature: -40C to 60C Material Specifications Body Material: Nylon Line Contacts: Phosphor Bronze Terminal Screws: Brass 8-32 Grounding Screw: Steel 8-32 w/ 12AWG Green 8 Inch Pigtail Mounting Screws: Zinc-Plated Steel 8-32 Face Material: Nylon Body Material: Polycarbonate Line Contacts: Brass Triple-Wipe Terminal Screws: Brass-Plated Steel Grounding Screw: Brass-Plated Steel Yoke: Zinc-Plated Steel Clamp Nuts: Zinc-Plated Steel Ground Clips: Brass-Plated Steel Shutter Mechanism: Delrin® Acetal Mechanical Specifications Terminal ID: Brass-Hot, Green-Ground, White-Neutral Terminal Accom.: 14-12 AWG Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral Terminal Accom.: 14-10 AWG Product ID: Ratings are permanently marked on device Torque Range: 14-16 inch pounds Performance Data UL1449 Impulse 6kV/500A L-N:330V MCOV: 150V rms Joules Rating: 720 Nominal Discharge Current Rating:3kA Maximum Surge Current, Per Mode (Per Phase): 27kA (L-N:18kA, L-G:9kA) Noise Rejection: -30dB at 500kHz-30MHz VPR: L-N:500V, L-G:600V, N-G:500V Short Circuit Current Rating: 5kA Diagnostics: Indicator Light Product Features Grounding: Grounding Termination: Side Body Material: Nylon UL1449 Impulse 6kV/500A L-N:330V Color: Ivory NEMA: 5-15R Standards and Certifications NEMA: WD-1 WD-6 UL498HG: File E13399 UL Fed Spec WC-596: File E13399 NEMA: WD-6 ANSI: C-73 Agency Certifications: UL 498, UL 1449 3rd Edition Listed and CSA C22.2 Certified Type 3 NOM: 057 Warranty Product Warranty: 10-Year Limited
