Light Organ - Color Organ - 5 Channel - 12V DC - Electronic Kit, US $2000 – Picture 0
Light Organ - Color Organ - 5 Channel - 12V DC - Electronic Kit, US $2000 – Picture 0

Light Organ - Color Organ - 5 Channel - 12v Dc - Electronic Kit

US $2000

  • Livermore, California, United States
  • Jun 9th
Open on mobile:
QR code
Bring Your Tunes to Life in a Blazing Color Light Show!! 5 Channel Light Organ - New 4th Generation Design! Runs on 12V DC - great for automotive installation - or Laser Light Show Splits your music into 5 frequency bands, each band controls one light circuit Each band's center frequency and width is adjustable This light organ circuit is so responsive you can 'see' vibrato in your music! Signal input from: Front panel condenser microphone Line level input from an iPod or computer sound card Speaker connection Automatic Gain Control circuit constantly adjusts input sensitivity to match changes in music level Input sensitivity is adjustable; ranging from just above a whisper to the loudest live music Includes a front panel with the Microphone, sensitivity control knob,and main power switch Expansion connector to optionally allow you to locate all the control pots and indicator LEDs to front panel location. Xkitz now offers a Control Panel kit here with LED tipped slide pots to control the 5 band levels and the main input level. You can build light organs with 10 channels, 15 channels, etc. using the XLO-5DC. The adjustable filter center frequencies makes this possible; using multiple XLO-5DC’s tuned to different center frequencies. 5 Indicator LEDs driven by the MOSFETs for testing before you hook up your lights Can source up to 2A per light driver circuit Makes a very unique sound-to-light device for the hearing impaired This kit includes two printed circuit boards and their related components: The main circuit board (5.75"x3.5"), which contains all the amplifiers, filters, MOSFET circuits necessary to drive 5 sets of lights. The front panel circuit board (2.875"x1.875") contains the condenser microphone, sensitivity level control and the main power switch. This is an advanced kit with about 110 components. This kit was designed and packaged in the USA Preview the Instruction Manual (.pdf)
