Low Frequency Tracking Antenna, 25db Amp, Patented Ferrite Design, 9khz To 1mhz

US $3,300.00

Auw, Germany
Jun 9th

Open on mobile:
QR code

LF (low frequency) Tracking Antenna Aaronia Magnotracker LF (9kHz to 1MHz) 9kHz to 1MHz patent pending, active, special ferrite tracking antenna. Details see manufacturers website at www.aaronia.com Only US$ 3300 incl. worldwide EXPRESS shipping and 10 years warranty! Frequency Range: 9kHz - 1MHz Design: Ferrite core, Active Internal Amplifier: 25dB (optional 35dB), battery powered (3-4 hours) or continuosly powered via included power supply Impedance: 50 Ohm RF connector: SMA (female), optional N connector Temperature range: - 20°C to +60°C Dimensions: (L/W/D): 66 x 32 x 11 cm Weight: 5000gr Incl. watertight transport case Weight case: 9kg Dimensions case: 113 x 42 x 16cm Warranty: 10 years Highlights: Perfect for magnetic field direction finding in combination with Spectrum Analyzers High Gain, internal 25dB pre-amplifier High Directionality Patented Functionality Compact Design 10 years warranty and manufactured in Germany A lot of customers have problems detecting and pin pointing signals in the low frequency range from 9kHz to 1MHz. They want one antenna with high gain to cover the full frequency range. The antenna should also offer a high directivity to pin point the signal(s). Till today such an antenna simply did not exist. Aaronia now offer world?s first patent pending magnetic antenna "Magnotracker" combining all those features. Based on a new patented production process Aaronia can produce this new cores with only 10% of the material and weight needed for similar working ferrites. A great advantage for the handling of the MagnoTRACKER antenna. The Aaronia Magnotracker is usable for the full frequency range of 9kHz to 1MHz without any adjustment. Simply connect it via SMA cable to your Receiver, Spectrum Analyzer, Oscilloscope, Power Meter etc. But the great advantage of the antenna is that you can also adjust it to ANY frequency within the full frequency range. With the help of 4 adjustment switches (Range: x1; x10; x100; x1000) and a fine pitch adjustment switch (Range: 1-16) to get a much higher gain at that special frequency working some sort as a filter or spectrum analyzer. This is a great feature to reduce unwanted signals and to focus on the signal of interest. Finding bugs or disturbing signals was never that simply and efficient. Made in Germany: All Aaronia antennas are developed, individually produced and calibrated in Germany at the Aaronia factory. This guarantees highest standard so that Aaronia can offer every customer a full 10 years warranty for all Magnotracker antennas.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Aaronia AG
Country/Region of Manufacture	Germany
Model	Magnotracker LF
Manufacturer	Aaronia
MPN	705
Unit Type	Antenna
