Lx6009 Automatic Boost Buck Converter 4-35v To 1.25-25v Cc Cv Voltage Regulator

US $36

GuangZhou, China
Jan 29th

Open on mobile:
QR code

LX6009 Automatic Boost Buck Converter 4-35V to 1.25-25V 2A CC CV Module Description Specifications: Module properties: Non-isolated boost buck constant current , constant voltage module (CC CV) charging module Input voltage: 4-35V ( Attention: if need constant current output, the input voltage at least 7V or above) Output voltage: 1.25-25V (continuously adjustable) Output cureent: 12V to 5V is 2A, constant current range:0.2-2A(adjustable) Turn lamp current: Fixed as 1/10 of the adjusted value of constant current Output power: natural cooling 10W,install heatsink can reach 15W Operating temperature: -40℃ to +85℃ (if temperature too high , please enhance heat dissipation) Full load temperature rise: 45 ℃ Indicator: constant current indicator is Red, when charging the indicator is Red, full charge the indicator is Green. Output short circuit protection: Yes, constant current(The value of constant current set up presently) Size: 48(L) *28(W) *13(H) mm Way for adjusting: First , connecting with power (Between 4-35V) , And monitor output voltage by multimeter ,then switch the potentiometer(Clockwise for voltage increase ,and anticlockwise for voltage decrease) Applications: High power LED constant current drive Lithium cell battery (including ferroelectric) , 4V,6V,12V,14V,24V charging battery ,nicel hydrogen cell (group ),nicel cadmium cell (group) charging . Solar panel,voltage stabilizing circuit of wind driven generator, a automotive voltage stabilizing power and some automotive buck-boost etc ,voltage stabilizing circuit. Direction for battery charging: Make sure the floating voltage ,charging battery and input voltage of battery you need Adjusting the constant potentiometer and put the output voltage on about 3V. Monitor the output short circuit current by multimeter ,and output the current to the expecting value of charging current by adjusting the constant current potentiometer. Default charging turn lamp current is 0.1 time current (Value of constant current), Please adjusting the turn lamp current potentiometer if you need.(Normally no need to adjust) Output voltage to the floating voltage by adjusting constant voltage. Connecting with battery and try to charge. (Step 1.2.3.4.5 is module input connecting with power ,while output no load disconnecting with battery.) Direction for LED constant current drive: Make sure the working current and max working voltage of LED you need to drive; Adjusting the constant voltage potentiometer and put the output voltage on about 3V. Monitor the output short circuit current by multimeter and output the current to your expecting LED working current by adjusting the constant current potentiometer . Output voltage to LED max working voltage by adjusting constant voltage potentiometer . Connecting with LED and try to operate . (Step 1.2.3.4. is input connecting with power , while output no load disconnecting with LED lamp. Package included: 1 x DC-DC Boost Buck Converter CC CV Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. We reserve the right to cancel your order if the payment is not made within 7 calendar days of checkout. We will use your Ebay/Paypal shipping address as the delivery address. Please make sure to provide us with correct and detailed shipping address. To Russia, please the receiver name must write your full name as post office required. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Shipping Detail All the items to USA will ship via ePacket with tracking number. To UK and Australia the buyer can choose "Expedited Int'l Shipping", we also will ship via ePacket with tracking number, it is better than registered mail,usually delivery time is 7-20 business day. But to Australia ZIP code 2898/2899/6798/6799/7151 can NOT ship via ePacket. Other countries, total price below $30 we will ship your item without tracking number. Otherwise, if you need Registered Mail shipping, please add $2.5(Can choose "Standard Int'l Shipping",we will ship via registered mail). Usually all the items will be shipped via Hong Kong Post Airmail or China Post Airmail. If you need the other express way(EMS/DHL/FedEx/UPS),please contact with us for the correct price. Your order will be dispatched within 2 business days after the full payment is cleared. Airmail Packets' Delivery Time(reference only): USA,Australia,New Zealand,Southeast Asia, East Asia. 7-20 business days. Most European countries (France,Spain,Germany,UK,Sweden, Norway, Denmark,Netherlands,Austria,Portugal, Croatia, Finland, Switzerland, etc.) ,Canada,10-25 business days. Some remote city will take more than 25 business day. Italy,Russia, Brazil, Turkey, Ukraine, India, 14-35 business days, 90% take long time. Eastern Europe,West Asia,Central Asia, 15-30 business days,80% take long time. Africa,Chile,Argentina,Mexico,Other Countries. 15-40 business days,usually long time. Delivery time depends on postal process and other factors(Weather,Vacation,Customs,etc.),it can receive as fast as 7 days,but it can take as long as 4-7 weeks in some cases. If you do not get your item in reference delivery time, please contact us first through ebay message (Please do NOT open any case), we will reply you as soon as possible(within 24 business hours). Return Policy Please contact us before you leave Negative or Neutral Feedback if you are not satisfied with our products,we will resolve it asap. DOA(Dead On Arrival) or Wrong Item will be offered exchange. Refund will be offered if stock is not available Defective goods must be returned within 30 days after receiving it for exchange or refund. Buyer is responsible for return shipping cost in any situations. Contact us Please feel free to contact us from ebay if you have any questions , we will reply you within 48 hours except the weekends and public holidays. Please contact with us before you leaving Negative or Neutral feedback, and please DO NOT open any case, we will try my best to resolve your problems ASAP. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	China
Output voltage	1.25-25V
Input voltage	4-35V
Output current	0.2-2A
