Macnaught Positive Displacement Flow Meter / Model Model# F050-2s2 / Erx-n/f

US $510

  • Shreveport, Louisiana, United States
  • Jun 9th
Macnaught Positive Displacement Flow Meter - ONE OF 2 AVAILABLE! Body: Aluminum with 2” 150# ANSI Flanged end connections Rotors: PPS O-Rings: FKM (Viton®) Pulse Output: Reed Switch output of 6.68 PPL (25.29 PPG) NOTE: Reed switch provides pulse to display Integral LC Display: Intrinsically Safe, Rate & Total, battery powered in ER heavy duty IP67/NEMA 4X aluminum enclosure Max. Temperature: 176? F (80? C) Min. Temperature: -40? F (-40? C) Max. Pressure: 260 PSI (18 Bar) Max. Viscosity: 1,000 cPs Flow Range with viscosity above 5 cPs: 4 to 130 GPM (15 to 500 LPM) Flow Range with viscosity below 5 cPs: 4 to 130 GPM (15 to 500 LPM) Cable entries: (3) 1/2 ” NPT (F) *****A Great Deal! My Sale Price was $3198.00 ea**** ****Please look at all pictures and specs and inquire if any questions.  Thank you!****
