Madell Px3700 Automatic Pick And Place- Complete Set W/ Reflow Oven W/ Conveyor

US $1100

  • Columbia City, Indiana, United States
  • Feb 13th
Open on mobile:
QR code
Complete Pick and Place Package for sale This was purchased for a prototype project and was only used to make aprox. 20 boards total. The project was stopped and we do not need this equipment now. Everything is in good working order. There is a PC with software for the pick and place and Reflow w/ conveyor, no PC for the Reflow oven.  Accessories for this equipment is included, as seen in pictures. Sold as a complete set only.  Complete Set Includes: 1) Madell Automatic tabletop Pick and Place - PX3700 Series 2) Madell Reflow Oven with Conveyor  - Model# EARF530 3) Madell SMT Reflow Soldering Oven - Model# QHL320A 4) Madell SMZ Tinocular Microscope - SMZ Series 5) Madell Manual Pick and Place - SMD-20B   Madell Automatic tabletop Pick and Place PX3700 Series Specs: 3000-3500 estimated pph (parts per hour) 21" x 29.5" PCB panel size Placement of 0603 standard, 0402 manageable by good operators (optional vision system for smaller parts) Up looking camera with optional computer vision system Fully programmable digital Z-axis and Theta rotation angles X and Y axis 0.0005" resolution, 0.001" positioning 80 feeder capacity-standard Fiducial recognition 12 month full factory warranty - parts & labor Easy to use graphic software for quick programming. Programming can be done manually with video camera or on screen Gerber file graphics. CAD file conversion can be accomplished with spreadsheet software 110 vac 60 Hz, 750 watts electrical 60 psi shop air required 180 lbs. net weight 38"w x 40"d x 21"h  Shipping:  Buyer is responsible for Freight scheduling and payment. Local pick up is welcome.
“Good condition. Front of Reflow oven shows a scratch.”
Brand Madell
Model PX3700
