MAGNELAB SCT-3000-1000 Current Transformer, 0.333 Voltage Output, US $310 – Picture 0
MAGNELAB SCT-3000-1000 Current Transformer, 0.333 Voltage Output, US $310 – Picture 0

Magnelab Sct-3000-1000 Current Transformer, 0.333 Voltage Output

US $310

  • Houston, Texas, United States
  • Jun 9th
Open on mobile:
QR code
                    AC Split-Core Current Sensor SCT-3000 Current Transformer, 0.333 Voltage Output 3" Opening up to 3000A Description Split-core current sensor transformers are designed to “sense” AC current from 400 to 3000 Amps passing through the center conductor. The Magnelab SCT-3000 Series current sensors are ideal for installation on existing electrical wiring by snapping around the conductor. The Magnelab SCT current sensor series has one of the highest industry standards both for interleaving joints and the self-locking mechanism. Features Output 0.333 Volt AC Accuracy at 10% to 130% of rated current Operates from 50 Hz to 400 Hz Linearity accuracy ± 1% Phase angle < 2 degrees measured at 50% rated current 8 ft. twisted-pair lead UL recognized Frequent Applications Data logging Recording Power monitoring Energy management Cost allocation PART NUMBER AND RATINGSCT-3000-000 No Burden Resistor* SCT-3000-400 400 Amp SCT-3000-600 600 Amp SCT-3000-800 800 Amp SCT-3000-1000 1000 Amp SCT-3000-1200 1200 Amp SCT-3000-1500 1500 Amp SCT-3000-2000 2000 Amp SCT-3000-3000 3000 Amp All Dimensions in InchesA 5.750 B 7.500 C 1.200 D 3.000
