Magnetics Inc ZF-43615-TC, F-140A-FC TOROID COATED FERRITE CORE (12 pieces lot), US $320 – Picture 0
Magnetics Inc ZF-43615-TC, F-140A-FC TOROID COATED FERRITE CORE (12 pieces lot), US $320 – Picture 0

Magnetics Inc Zf-43615-tc, F-140a-fc Toroid Coated Ferrite Core (12 Pieces Lot)

US $320

  • Orange, California, United States
  • Jun 3rd
Open on mobile:
QR code
MAGNETICS INC ZF-43615-TC  FERRITE CORE, COATED TOROID, F MATERIAL, Permeability 3000 You are buying a lot of (12 pieces).  Part Number: ZF-43615-TC / F-140A-FC (coated) Manufactured by Magnetics Inc, Pennslyvania, USA Core Type: Toroids Toroid Core Size: OD = 36 mm (1.417 inch) x ID = 23 mm (0.906 inch) x HT=15 mm (0.59 inch)   Material Grade: F Permeability of 3000, Max Permeability 4300 Saturation Flux density 4700 gauss  at 10 oersted, 25 deg C Residual Flux Density 900 gauss, Volume resistivity 100 ohms-cm, Curie temp 250 deg C. Le = Effective Magnetic Path Length: 8.97 cm  Ae = Effective Cross Section Area: 0.946 cm2  Ve = Volume : 8.48 cm3 Al = Inductance Factor : 4040 nH  RoHS Compliant Application / Uses :  F material with permeability of 3000 is the most widely used ferrite core for switch mode power supplies in 20 Khz to 300 Khz. It is also used as EMI/RFI filters and common mode chokes for 1000 Khz to 50 Mhz.
