Manual For Tektronix Distortion Analyzer Set Tm504a Aa501a Sg505 Mod Wq Wr

US $24.19

  • Chandler, Arizona, United States
  • Jun 9th
Open on mobile:
QR code
Tektronix Distortion Analyzer Test Set Xerox reprinted manual 101+ pages Includes detailed pages on the; TM504A AA501A SG505 MOD WQ SG505 MOD WR If you have been having difficulty getting the correct results from your gear, it could be because you don't have the proper documentation. Tektronix made up a special Distortion Test Set consisting of the items listed above.  Success with this system depended upon buying these components as a set or building a set properly. In order for these units to cross talk, the units had to be assembled in a particular way. Using the wrong components, SG505 Oscillators/TM504 cases or improper assembly would defeat the cross talk capability. We found the original Tektronix manual for the complete test set. That manual is 30 years old. We did our best to individually scan, correct and make those pages as readable as possible. We added numerous pages of related information and created our own compilation. It is available only as a Black & White Xerox reprinted version. The manual is supplied unbound to allow your choice of binding method. We can print the cover in color on request at a small additional fee. Get this compilation now and learn why you have been unable to get the maximum use from your system. The compilation shows how to interface these plug-ins with Scopes and Spectrum Analyzers, etc. This 101 page manual has all of the original information in readable detail on looseleaf pages.  It can be read while laying flat on your test bench. This is much preferred over DVD's etc. Contact Dick Wilson at DiLette Sales in Chandler, Arizona for more information.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Tektronix
Exact type Audio Distortion Analysis
Product Type Instruction Manual
manual type paper or electroni Distortion Analyzer test Set manual
Subject Area Distortion Analysis in Audio Systems
