Marathon 56t17d2113 General Purpose Three Phase Motor Dripproof, Rigid Base

US $75.00

  • Homestead, Florida, United States
  • Jun 9th
Open on mobile:
QR code
Model: Brand Marathon Electric Mfg part number 56T17D2113 Mechanical Specifications: Motor primary use General Purpose Horsepower 1 RPM 1800 Rotation Reversible Frame size 56 Enclosure type ODP Mounting Foot Connection box Side Shaft diameter (in) 0.625 Shaft type Smooth shaft w/ 0.19 x 0.19 key Shaft height (from base) (in) 3.5 Overall length (in) 11.47 Overall height (in) 6.32 Bearings Ball bearings Frame material Rolled steel Electrical Specifications: Phase Three Voltage 200-208 Amperage (full load) 3.9 Frequency (Hz) 60 Service factor 1.15 Duty cycle Continuous-use rated Full load efficiency (%) 76.5 Integrated overload protection No Inverter rated Yes Foot Mount Specifications: Base type Rigid Mounting hole pattern length (in) 3 Mounting hole pattern width (in) 4.88 Other Information: Agency approvals CSA Approved, UL Recognized Warranty 12 months from date of installation, 18 months from date of manufacture Weight & Dimensions: Weight 23.00 lbs. (10.43 kg) LxWxH 11.47 x 6.50 x 6.32 in.  (29.13 x 16.51 x 16.05 cm)
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Marathon
