Max7219 Dot Arduino Matrix Display Module Cascade Control Arduino Chip Diy Kit

US $2.14

Hong Kong, China
Jan 29th

Open on mobile:
QR code

Ebay Shops Payment Delivery Time Surport & Warranty Store Policy Visit store: tinxi-clothes-shop Welcome to Tinxi store Coustom Notice - Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Please check with the local customs office to determine what these additional costs will be prior to bidding/buying. - We are a company in CHINA. Delivery from China will cost approximately 20-30 working days. Please pay attention to the shipping and delivery time before you bid. Thank you. Search Product Details MAX7219 Dot Arduino Matrix Display Module Cascade Control Arduino Chip DIY Kit Article-Nr.:5200802 Product Details: Matrix Module Condition: New Absolute maximum ratings: Voltage (with respect to GND) DIN, CLK, LOAD, CS: -0.3V to 6V Current DIG0-DIG7 Sink Curr: 500mA SEGA-G, DP Source Current: 100mA Continuous Power Dissipation (TA=+85°C) Narrow Plastic DIP: 0.87W Wide SO: 0.76W Narrow CERDIP: 1.1W Operating Temperature Ranges(Max7219) MAX7219: 0°C to +70°C Storage Temperature Range: -65°C to +160°C Lead Temperature (soldering, 10sec): +300°C Application:Education,DIY, Robot,etc Feature: 1.Seamless splicing and so that the dot matrix c--an be flexible spliced . 2.Common cathode with bright dot matrix(8*--8), display fresh and brilliant picture. 3.A screen roll freely, to achieve the perfect pi--ture display 4.Since the master chip is used in Max7219 to- make product have the following characteris--tics : 1).The transmission efficiency of up to 10MHz. 2).Can be individually controlled for each point. 3).Lowest power consumption of 450uA (one m--odule). 4).Power-on reset automatically display full black 5).Serial communication, a great saving of MCU IO, also can be extended To expand the prog--ram with SPI. 6).For each screen brightness control, by setting the Max7219 instructions. PIN Define : CLK Serial-Clock Input. 10MHz maximum rate. CS Chip-Select Input. Serial data is loaded into the shift register while CSis low. DIN Serial-Data Input. Data is loaded into the internal 16-bit shift register on CLK's rising edge DOUT Serial-Data Output. The data into DIN is valid at DOUT 16.5 clock cycles later. VCC Positive Supply Voltage. Connect to +5V. GND Ground Color show as pictures. PLS NOTE that due to lighting effects, monitor's brightness / contrast settings etc, there could be some slight differences in the color tone of the pictures and the actual item! Package Included: 1 x Matrix Module Powered By Tinxi

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	See Description
Brand	See Description
